Section 4: Adjustment
Source range
4 A
5 A
7 A
10 A
* DMM reading used in corresponding adjustment step. See the adjustment procedure in
Remote adjustment procedure
4-6
Source current DMM current reading*
+4.0000 A
+000.00 A
−4.0000 A
−000.00 A
+5.0000 A
+000.00 A
−5.0000 A
−000.00 A
+7.0000 A
+000.00 A
−7.0000 A
−000.00 A
n/a
(on page 4-7).
Model 2461 Calibration and Adjustment Manual
____________________________ A
____________________________ A
____________________________ A
____________________________ A
____________________________ A
____________________________ A
____________________________ A
____________________________ A
____________________________ A
____________________________ A
____________________________ A
____________________________ A
There are no adjustment steps for the 10 A
range.
