Section 4: Adjustment

Remote adjustment

Use the following procedure to perform remote adjustment by sending SCPI commands over the
IEEE-488, USB, or LAN connection. The remote commands and appropriate parameters are
separately summarized for each step.
You can use the following tables to document each calibration adjustment value as the calibration
adjustment procedure is executed.
Voltage calibration adjustment data table
Source range
0.2 V
2 V
7 V
10 V
20 V
100 V
* DMM reading used in corresponding adjustment step. See procedure.
4-4
Source voltage Digital multimeter (DMM) voltage reading*
+200.00 mV
+000.00 mV
−200.00 mV
−000.00 mV
+2.0000 V
+0.0000 V
−2.0000 V
−0.0000 V
+7.000 V
+0.000 V
−7.000 V
−0.000 V
+10.00 V
+0.000 V
−10.00 V
−0.000 V
+20.000 V
+00.000 V
−20.000 V
−00.000 V
+100.00 V
+000.00 V
−100.00 V
−000.00 V
Model 2461 Calibration and Adjustment Manual
____________________________ mV
____________________________ mV
____________________________ mV
____________________________ mV
____________________________ V
____________________________ V
____________________________ V
____________________________ V
____________________________ V
____________________________ V
____________________________ V
____________________________ V
____________________________ V
____________________________ V
____________________________ V
____________________________ V
____________________________ V
____________________________ V
____________________________ V
____________________________ V
____________________________ V
____________________________ V
____________________________ V
____________________________ V
