Analog Input (J6)

3.4 Analog Input (J6)
PIN NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
23
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
3.5

Digital Audio Interface, Output (J9)

The digital audio interface contains digital audio signal data (I
for signal timing and details not explained in this document.
26 System Interfaces
Table 3-4. J6 Pin Description
NET-NAME AT SCHEMATICS
GND
LineIn1L
GND
LineIn1R
GND
LineIn2L
GND
LineIn2R
GND
LineIn3L
GND
LineIn3R
GND
LineIn4L
GND
LineIn4R
GND
LineIn5L
GND
LineIn5R
GND
LineIn6L
GND
LineIn6R
GND
LineIn7L
GND
LineIn7R
GND
LineIn8L
GND
LineIn8R
GND
LineIn9L
GND
LineIn9R
GND
LineIn10L
GND
LineIn10R
DESCRIPTION
Ground
Line in left channel 1 also on RCA J5
Ground
Line in right channel 1 also on RCA J5
Ground
Line in left channel 2
Ground
Line in right channel 2
Ground
Line in left channel 3
Ground
Line in right channel 3
Ground
Line in left channel 4
Ground
Line in right channel 4
Ground
Line in left channel 5
Ground
Line in right channel 5
Ground
Line in left channel 6
Ground
Line in right channel 6
Ground
Line in left channel 7
Ground
Line in right channel 7
Ground
Line in left channel 8
Ground
Line in right channel 8
Ground
Line in left channel 9
Ground
Line in right channel 9
Ground
Line in left channel 10
Ground
Line in right channel 10
2
S), clocks, etc. See TAS3308 Data Manual
