This user's guide describes the operation of the TAS5766MDCAEVM. The TAS5766MDCAEVM is
connected to the PurePath™ Console Motherboard (PPCMB). For questions and support go to the E2E
forums (e2e.ti.com). The main contents of this document are:
•
Hardware descriptions and implementation
•
Start up procedure using PurePath Console (PPC) software with TAS5766M plug-in
Related documents:
•
TAS5766M Data Sheet (SLASE25)
•
PurePath Console Motherboard User's Guide (SLOU366)
•
PurePath Graphic Development Suite
1
1.1
1.2
1.3
2
2.1
2.2
3
3.1
3.2
3.3
3.4
3.5
4
4.1
4.2
4.3
1
2
3
4
5
6
7
8
9
2
10
Direct I
C Access
11
Device Registers Tab
12
13
(PurePath
..........................................................................................................
....................................................................................
...................................................................................
................................................................................................
.....................................................................................................
................................................................................................
...............................................................................................
...................................................................................
...................................................................................................
............................................................................................
2
C Access Tab
.............................................................................................
....................................................................................................
................................................................................
.........................................................................................
..............................................................................................................
.........................................................................................................
...............................................................................................................
.........................................................................................
.................................................................................................
...............................................................................................
........................................................................................................
...........................................................................................................
......................................................................................................
Copyright © 2014, Texas Instruments Incorporated
TAS5766MDCAEVM
Console)
Contents
.......................................................................
...................................................
......................................................................
...........................................................................
List of Figures
..........................................................................
.......................................................................
...................................................................
User's Guide
SLOU382 - June 2014
2
2
3
3
4
4
5
6
6
7
8
10
10
11
11
12
13
2
3
4
5
5
6
7
8
9
10
10
11
11
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TAS5766MDCAEVM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Texas Instruments TAS5766MDCAEVM

Summary of Contents for Texas Instruments TAS5766MDCAEVM

  • Page 1: Table Of Contents

    SLOU382 – June 2014 TAS5766MDCAEVM This user’s guide describes the operation of the TAS5766MDCAEVM. The TAS5766MDCAEVM is connected to the PurePath™ Console Motherboard (PPCMB). For questions and support go to the E2E forums (e2e.ti.com). The main contents of this document are: •...

  • Page 2: Hardware Overview

    TAS5766M is an I2S or TDM input class D amplifier with PurePath Smart Amp. The EVM is used in conjunction with the PurePath Console Motherboard (PPCMB). The PVDD supply is provided via the TAS5766MDCAEVM and is regulated to 5 VDC and 3.3 VDC on the PPCMB. The PPCMB provides the I2S, I2C and 3.3 VDC to the TAS5766MDCAEVM.

  • Page 3: Tas5766Mdcaevm Functions

    TAS5766M. Upon PPC execution and connection, the TAS5766M is put in software mode. The digital audio data input to the TAS5766MDCAEVM is sent from PPCMB and is selectable from USB audio, optical SPDIF, coaxial SPDIF, and analog ADC sources. When a digital audio data input is selected, the PPC automatically sends appropriate scripts to the device in use.

  • Page 4: Tas5766Mdcaevm Setup

    • Connect the PPCMB to the TAS5766MDCAEVM • Connect the PSU to TAS5766MDCAEVM and turn on the power. 5-V and 3.3-V LEDs are illuminated. • If an optical SPDIF source is used, the blue SPDIF clock-locked LED is illuminated •...

  • Page 5: Software Installation

    Execute the GUI installation program, Setup_PurePathConsole_Main_vxx_revxx.exe. Once the program is installed, the program group and shortcut icon is created in Start → Program → Texas Instruments Inc → PurePath Console → Choose Target. The Target Selection window is displayed; select TAS5766M –...

  • Page 6: Using The Purepath Console With The Tas5766Mdcaevm Board

    On the PPC, the green LED on the bottom left corner is on Using the PurePath Console with the TAS5766MDCAEVM Board The TAS5766MDCAEVM is initialized upon PurePath Console startup. Audio is streaming to the speakers if Windows Media (or similar program) is playing and mini-USB EVM is selected in the sound playback properties.

  • Page 7: Tas5766M Block Diagram Tab

    Using the PurePath Console with the TAS5766MDCAEVM Board www.ti.com TAS5766M Block Diagram Tab This tab, illustrated in Figure 7, shows the device major blocks. Some of the blocks are selectable. When a block is selected (double click), it shows pop-up settings for the particular setting.

  • Page 8: Pop-Up Windows

    Using the PurePath Console with the TAS5766MDCAEVM Board www.ti.com Pop-Up Windows For TAS5766M, there are several settings that are done via I2C. The GUI facilitates these settings seamlessly using the pop-up windows seen in Figure 8 Figure Figure 8. Smart Amplifier GUI Pop-Up TAS5766MDCAEVM SLOU382 –...

  • Page 9: Biquad Block Pop-Up

    Using the PurePath Console with the TAS5766MDCAEVM Board www.ti.com Figure 9. Biquad Block Pop-up SLOU382 – June 2014 TAS5766MDCAEVM Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...

  • Page 10: Direct I 2 C Access

    Using the PurePath Console with the TAS5766MDCAEVM Board www.ti.com Direct I C Access Tab C registers read and write can be performed on this tab (see Figure 10). Type in the device I C address and click Set. On the Direct I...

  • Page 11: Board Layouts, Bill Of Materials, And Schematics

    Board Layouts, Bill of Materials, and Schematics TAS5766MDCAEVM Board Layouts Figure 12 Figure 13 illustrate the board layouts for the EVM. Figure 12. TAS5766MDCAEVM Top Composite Assembly Figure 13. TAS5766MDCAEVM Bottom Composite Assembly SLOU382 – June 2014 TAS5766MDCAEVM Submit Documentation Feedback...

  • Page 12: Bill Of Materials

    Board Layouts, Bill of Materials, and Schematics www.ti.com Bill of Materials Table 1 displays the BOM for this EVM. Table 1. TAS5766MDCAEVM Bill of Materials Item MFG Part Num Ref Designators Description TAS5766DCA TEXAS NO DATA YET HTSSOP48-DCA ROHS INSTRUMENTS...

  • Page 13: Tas5766Mdcaevm Schematic

    0.22ufd/50V PVDD 0.01ufd/50V 1.0ufd/50V 1.0ufd/50V 1.0ufd/50V 100K OUTPL OUTL+ 4.7uH/5.1A 1.0ufd/50V 220ufd/50V +3.3V 3.3/5% 0.68ufd/50V 0.22ufd/50V 10.0K 0.01ufd/50V Figure 14. TAS5766MDCAEVM Schematic (Page 1 of 2) SLOU382 – June 2014 TAS5766MDCAEVM Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
  • Page 14 GPIO3 (CCB-GPIO4) ADR1 (CCB-GPIO9) GPIO1 GPIO2 ADR2 GPIO3 (CCB-GPIO10) R-GND LRCLK MAIN POWER IN LRCLK PVDD L-GND ADR1 Figure 15. TAS5766MDCAEVM Schematic (Page 2 of 2) TAS5766MDCAEVM SLOU382 – June 2014 Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated...
