RH Baby&child BELLINA STORAGE CONVERSION CRIB Assembly Instructions Manual page 10

STEP 5
TODDLER RAIL ASSEMBLY
STEP 5.1
Loose all the bolts in both ends of the front side rail to disassemble it.
STEP 5.2
Slightly loosen the bolt at the back of the headboard just enough to set
the toddler rail in between the side rails.
STEP 5.3
Inside each side rail is a cavity for the hook that corresponds to the
hook on both ends of the toddler rail. Align and insert the hook of the
toddler rail into the cavity of the side rails as shown in DETAIL J.
NOTE: If mattress support is not in the lowest position, unscrew
mattress support bolts and move the lowest position.
STEP 5.4:
The unused holes can hurt your child's fingers. Use the Allen bolts (EE)
provided (packed inside toddler rail box) to hide these holes.
See DETAIL K.
DETAIL K
(EE)
HARDWARE FOR STEP 5:
(PACKED INSIDE TODDLER RAIL BOX)
(EE) 1/4" x 1/2" Allen Bolt = 2 pcs.
DETAIL J
Allen Wrench = 1 pc.
K
J
10/11
