Chesterfield Bunk Bed Storage With Ladder - Assembly Instructions
Made In China
!
WARNING: Read all instructions before assembling
this product. KEEP INSTRUCTIONS FOR FUTURE USE.
CUSTOMER SERVICE
If you are missing parts or have any questions about this product, contact us first. You
can also order parts writing to the address above. Include the product model number,
color, and a brief description of the part. Call 1-800-762-1751
CARE AND CLEA
NINGCAGCARE AND CLEANING
DO NOT use abrasive chemicals for cleaning. Dust often using a clean, soft dry cloth add
period & Dab spills quickly with a soft cloth. Vacuum to remove dust.
If the Bunk Bed is to be stored, store in a cool dry place andcarefully package all original
hardware to protect from loss.
