Trek 2022 CHECKPOINT SL Service Manual Supplement page 9

T47 bottom bracket
Install the bottom bracket
1. Apply grease to the threads on both sides of the
frame.
2. Using your hands, thread the bottom bracket onto
the frame.
NOTICE: Do not start tightening the bottom bracket
with a tool. Dirt and other contaminants can
damage the threading.
3. Use the proper tool to torque both sides to
specification (see the Tool and spline compatibility
table below).
4. If necessary, add spacers before installing the cranks
(see the Spacers required
Tool and spline compatibility
Tool
Model
Part number
24mm
Praxis
30mm
Wheels MFG
SRAM DUB
Chris King
24mm
Ceramic-
Speed
GXP
table at the top right).
Praxis Unior
TP-2400 TP-3028 1671.T47
594148 594147 1043614
X
X
Spacers required
The table below contains bottom bracket/crank
combinations that require spacers. Your bicycle may have
other combinations that do not require spacers.
Crank Bottom bracket
CeramicSpeed
Shimano
24mm
DUB SRAM DUB
SRAM
GXP Wheels MFG
driveside
washer
SRAM GXP cranks
only
Park Tool Wheels Mfg
BBT-47 BBTOOL-48-44
568922 589307
X
X
X X
X X
X X
2022 Checkpoint SL/SLR
Spacers required
Drive
side
0.5mm
2-3mm
1.0mm
non-driveside
washer
CeramicSpeed
—
X
X
X
Non-drive
side
0.5mm
—
—
8
