- Page 1 2023 FX+ / DUAL SPORT+ SERVICE MANUAL SUPPLEMENT...
- Page 2 If a threadlock- the Electric bikes section at trekbikes.com/manuals. er is not applied, the fasteners may loosen, which could damage the bicycle and result in injury to the rider. Copyright 2022 Trek Bicycle Corporation All Rights Reserved...
- Page 3 2023 FX+ / Dual Sport+ Brake/shift routing 2Nm. Derailleur hanger bolts (M3x7 mm) – W318604 Derailleur hanger – W5268484 Rear derailleur cable Rear brake hose Front brake hose...
- Page 4 2023 FX+ / Dual Sport+ E-system components and routing 11 Nm 6 Nm. 6 Nm. 11 Nm 3 Nm. 2 Nm. 2Nm. 3 Nm. Before removing the rear wheel Hub motor – W5266204 Shift to the smallest rear cog (highest gear). Remote –...
- Page 5 2023 FX+ / Dual Sport+ Battery and controller assembly AUTHORISED DEALERS ONLY: Only authorised dealers should perform service on the e-system. Improper handling, tools used or torque applied to these parts may result in damage to the e-system components and cables. Remove the battery Remove the bottom bracket cover (9).
- Page 6 2023 FX+ / Dual Sport+ Battery and controller assembly (continued) Install the battery Install and tighten the bolts (6) to 6 Nm. Use the four bolts (7) to attach the controller to the battery. Torque the bolts to 3 Nm. Slide the battery assembly into the down tube –...
- Page 7 2023 FX+ / Dual Sport+ Bottom bracket/torque sensor AUTHORISED DEALERS ONLY: Only authorised dealers should perform service on the e-system. Improper handling, tools used or torque applied to these parts may result in damage to the e-system components and cables. Remove the bottom bracket Install the bottom bracket Remove the chain guard, cranks and pedals before...
- Page 8 2023 FX+ / Dual Sport+ Fork and headset Spacer (5 mm) – 5253930 Headset routing cap – W5260269 Routing split ring – W5294453 30 mm Headset bearings – 5269847 Optional spacers Crown race reducer – 5283141 Split ring routing Front Rear light brake...
- Page 9 2023 FX+ / Dual Sport+ Chain guard (aftermarket on Dual Sport+) 4Nm. 4Nm. 4Nm. Bolts (M5x8 mm) Washers (M5) 5284386 Seat stay bracket Chain guard...
- Page 10 2023 FX+ / Dual Sport+ Mudguards and rack (aftermarket on Dual Sport+) 3Nm. 4Nm. 3Nm. 3Nm. 4Nm. 3Nm. 4Nm. Knurled washers Stay clips 5258253 Locknut (M5) Damping rubbers 5260273 Bolt (M5x30 mm) Mudguard stay (330 mm) – W1049503 Bolt-nuts – W317707 Mudguard stay (310 mm) –...
- Page 11 2023 FX+ / Dual Sport+ Light routing – FX+ NOTE: These lights are designed for 6 volts. If you use a light with a higher voltage, it may not function properly and could take power away from the e-bike motor. –...
- Page 12 2023 FX+ / Dual Sport+ Light routing – Dual Sport+ NOTE: These lights are designed for 6 volts. If you use a light with a higher voltage, it may not function properly and could take power away from the e-bike motor. –...
- Page 13 2023 FX+ / Dual Sport+ Specifications FX+ / Dual Sport+ 144.5 mm Rear hub outer limit dimension (OLD) Front hub outer limit dimension (OLD) 100 mm Fork steerer tube outer dimension (OD) 28.6 mm Bottom bracket type/width Brake rotor diameter min/max 160 mm Chainline 49 mm...
