Trek 2022 CHECKPOINT SL Service Manual Supplement page 2

Contents
Safety Brake/shift routing —
Headset and fork
Chainkeeper
Safety
WARNING
Properly tighten hardware
Always tighten hardware to the specified torque.
Over-tightening hardware could deform or break the
hardware or components. Under-tightening hardware
could cause hardware or components to become loose.
Either situation could damage the bicycle and result in
injury to the rider.
WARNING
Reapply threadlocker
All reused-fasteners with pre-applied threadlocker must
be cleaned with isopropyl alcohol and have new thread-
locker applied before re-assembly. If threadlocker is not
applied, the fasteners may loosen which could damage
the bicycle and result in injury to the rider.
Brake routing — eTap
mechanical
IsoSpeed — SL IsoSpeed — SLR
Accessories — SL Accessories — SLR
Copyright 2021 Trek Bicycle Corporation All Rights Reserved
Brake/shift routing —
Di2
Storage door
Specifications
Legend
Apply grease
Do not apply grease
Apply threadlocker
Torque
Nm
 
Zip tie
2022 Checkpoint SL/SLR
