Accessories — SL
Water bottle cage adapters
For frames 54cm or larger, you can fit three water bottle
cages in the frame triangle using the adapters.
5
3
2
1 Fender mount bolts — 317700
Bolt (M5x8mm) — 596823
2
3 Bolt (M5x16mm) — 596821
4 Frame bag
5 Water bottle cage adapters — W5271627
Mounting inserts
All mounting inserts are M5x0.8.
Rack, fenders, and frame bag
NOTE: Use only steel fasteners to attach racks, bags, and
fenders. Do not use aluminum fasteners as they are not
rated for these loads.
Rack
Rear fender
1
2022 Checkpoint SL/SLR
4
Front fender
