- Page 1 2022 MADONE SL SERVICE MANUAL SUPPLEMENT...
-
Page 2: Table Of Contents
(Loctite 243 or equivalent) before re-assembly. If a threadlocker is not applied, the fasteners may loosen, which could damage the bicycle and result in injury to the rider. Copyright 2021 Trek Bicycle Corporation All Rights Reserved... -
Page 3: Brake Lines
2022 Madone SL Service Manual Brake lines 25mm The calliper mounting bolt channel is 25 mm on all 2022 Madone SL bicycles. Route the rear hose Housing grommet – W330578 Connect the calliper to the rear brake hose using a DuoTrap cover –... -
Page 4: Shift Cables - Mechanical
2022 Madone SL Service Manual Shift cables – mechanical 2–3 Nm eTap only 6 Nm 3 Nm 2–3 Nm Front derailleur bolt – W543903 Rear housing grommet – W317292 Chainkeeper parts – 5373827 Rear derailleur hanger – W524188 Control centre – W1044890 Rear derailleur hanger bolts –... -
Page 5: T47 Bottom Bracket (Bb)
2022 Madone SL Service Manual T47 bottom bracket (BB) Install the BB Spacers required The table below contains BB/crank combinations that Apply grease to the threading on both sides of the require spacers. Your bicycle may have other combinations frame. that do not require spacers. -
Page 6: Fork And Headset
2022 Madone SL Service Manual Fork and headset 2–4 Nm 9–10 Nm The arrow on the expander plug must face forward. optional spacers 0.7 Nm Steerer stop bolt – W318529 Expander plug – W5257464 Steerer stop – W5265664 Spacer (5 mm) – 5253930 Split ring –... - Page 7 2022 Madone SL Service Manual Fork and headset Install the headset Clean the steerer tube using isopropyl alcohol. Assemble the headset to the stem as shown on page 5. Make sure the stem is in its final position Grease both bearings, the crown race and the inside with the required spacers underneath.
-
Page 8: Isospeed
2022 Madone SL Service Manual IsoSpeed NOTICE: Carefully remove the covers with a paint-safe plastic pry-bar. 8 Nm To adjust the ride feel, loosen both bolts shown 2 Nm above and move the slider. 2 Nm 2 Nm NOTICE: Do not apply grease to the frame pockets. -
Page 9: Seatpost
2022 Madone SL Service Manual Seatpost 9 Nm 7 Nm 4 Nm 5 Nm Wedge Bolt Plate Wedge bolts kit W574676 Pinch bolt Pinch bolt/saddle tilt clamp ears (7x7 mm) – W524900 Seatpost tail – W557630 Seat mast cap (dark grey as shown) – W569842...
