The SD-Series Card Printers

C
D
A = Swingarm
B = Latch Button
C = Cover Ridges
D = Manual Advance Knob
E = Printer Connections
F = Card Input Hopper
Front Panel
Power
Button
A
B
E
F
Up
Down
Arrow
Arrow
User Reference Guide
K
J
G = Card Output Hopper
H = Front Panel
I = Exception Slot
J = Print Ribbon Cartridge
K = Printhead
LCD Front Panel
Status Lights
Ribbon
Cards
User Light &
Enter
User Button
I
H
G
