Entrust SD460 Quick Install Manual

Slm laminating system
Hide thumbs Also See for SD460:

Advertisement

Quick Links

Download this manual
Quick Install Guide
SD460™ SLM Laminating
System
October 2020
527442-001, Rev G

Advertisement

loading
Need help?

Need help?

Do you have a question about the SD460 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Entrust SD460

Summary of Contents for Entrust SD460

  • Page 1 Quick Install Guide SD460™ SLM Laminating System October 2020 527442-001, Rev G...
  • Page 2 SD460 Laminating System WARNING: This product contains chemicals, including lead, known to the State of California to cause cancer, and birth defects or other reproductive harm. Wash hands after handling. WARNING: This product can expose you to chemicals including Di(2-ethylhexyl)phthalate (DEHP), which is known to the State of California to...

  • Page 3: Before You Begin

    Refer to the printer’s Installation and Administrator’s Guide, found on the Owner’s Library CD that ships with the printer, for detailed installation instructions. The latest user documentation and firmware for the SD460 system is available for download at www.entrustdatacard.com. 1. Select a Location for the System Install the system in a location that is large enough for your system configuration.
  • Page 4 SD460 Laminating System 2. Unpack and Secure the System a. Remove the printer and the laminator from the shipping cartons. The SD460 Quick Install Guide (this guide) is included in the shipping carton. Save the shipping cartons and packing materials.
  • Page 5 Quick Install Guide b. Secure the laminator to the mounting surface (optional). Refer to the printer’s Installation and Administrator’s Guide for detailed measurements and instructions. Carefully tip the laminator onto its left side (the side without the access door). Insert the M6 well nuts into the bolt-down openings in the bottom of the laminator.
  • Page 6 SD460 Laminating System 3. Assemble the Printer and Laminator a. Locate the interconnect cable in the cable routing area at the top of the laminator and make sure that it remains accessible. Laminator Front Laminator Interconnect Back Cable b. Open the laminator access door.
  • Page 7 Quick Install Guide d. Lift the printer over the laminator and align the pins on the laminator with the holes on the underside of the printer. e. Press down on the printer carefully, but firmly, to position it. Push the printer locking lever to the right to lock the printer to the laminator.

  • Page 8: Connect The Power Cords

    SD460 Laminating System 4. Connect the Power Cords a. Connect the printer power cord to the printer and to the power supply. Plug the power supply cord into the power outlet. Front Back b. Connect the laminator power cord to the laminator and to the power supply.
  • Page 9 Quick Install Guide 5. Load Laminator Supplies Supplies are ordered separately. Refer to the SD260L/SD360/SD460 Card Printers Quick Install Guide to load printer supplies. The L1 (green) and L2 (orange) cartridges fit only in their assigned locations inside the laminator. They are not interchangeable.
  • Page 10 SD460 Laminating System c. Load the overlay onto the cartridge. Make sure that the overlay spool color matches the cartridge spindle.
  • Page 11 Quick Install Guide d. Replace the cartridge in the laminator. e. Remove the L2 (orange) cartridge, if installed, from the laminator. Repeat Steps 5c and 5d to load the overlay onto the L2 cartridge. g. Close the laminator access door when finished.

  • Page 12: Power On The System

    The laminator status light blinks blue while the heaters are warming up. 7. Install the Card Printer Driver Refer to the SD260L/SD360/SD460 Card Printers Quick Install Guide or the XPS Card Printer Driver User’s Guide to install the Card Printer Driver and connect the system...

  • Page 13: Print A Test Card

    Quick Install Guide 8. Print a Test Card Use the printer’s LCD panel to print a test card. The card tests the L1 and L2 laminators (if L2 is installed), debows the card, and impresses the card if an impresser is installed.
  • Page 14 SD460 Laminating System 9. Verify the Test Card Examine the test card to verify the following: • The overlays are applied properly: • Each overlay is applied completely to the card. • The material adheres well to the edges of the card.
  • Page 15 Quick Install Guide Notes...
  • Page 16 Entrust, Sigma and the hexagon design are trademarks, registered trademarks and/ or service marks of the Entrust Corporation in the United States and other countries. Datacard is a registered trademark and service mark of Entrust Corporation in the United States and other countries. All other trademarks are the property of their respective owners.
