Installation -
Installation
Before installing your camera, you have to read the following cautions.
1. You have to check whether the location can bear five times of the weight of your camera.
2. Don't let the cable to be caught in improper place or the electric line cover to be damaged. Otherwise
it may cause a breakdown or fire.
3. When installing your camera, don't allow any person to approach the installation site. If you have any
valuable things under the place, move them away.
Reset
T-W Jog Button
Test Video Output
Reset to the Factory Default
Press the reset button for 5 seconds to return the setup
to the factory default.
Warning
If you press the 'Reset' button, you will lose all setting
data. If needed, please, make a note for further
installation.
1
Using the Template sheet, make the cabling hole on
the wall/ceiling.
2
Connect the network cable, power cable respectively.
See the section 'Installation - Cabling' for details.
3
Fix the camera on the wall/ceiling by screw provided.
Loosen the Pan/Tilt stoper screw a litte before fixing the camera.
4
By using the test video cable, check the screen during
SD Card Slot
installation. You can adjust the zoom ratio using the
T-W jog button.
WIDE
TELE
Zoom Out
Zoom In
