Digital Watchdog MEGApix CaaS DWC-MB44LPRC2 User Manual page 65

Setup - System Setup
Firmware Update
9
4
FTP Server Address
Define FTP Server IP Address. If IP Address form is incorrect,
a Message box will be shown to try again.
5
FTP Port
Define the FTP Server Port. If Port is not appropriate, it is
impossible to access to FTP Server.
6
User ID
Define User ID to access to the FTP Server. Fill out the correct
User ID registered in the FTP Server.
7
Password
Define Password to access to the FTP Server. Fill out the
correct Password registered in the FTP Server.
8
FTP Upload Path
Define a path in FTP server to store video. For the path name,
English Alphabets, numbers and special characters
( / ~ ! @ $ ^ ( ) _ - { } [ ] ; , ) can be used.
9
Click 'Save' to make above setting effective.
SAVE Save FTP information
CANCEL Click 'Cancel' to return to the previous setting.
Check the F/W file and if the file exists, 'F/W Update'
CHECK
button will appear and click it to update for F/W.
67
4
5
6
7
8
