Bill Of Materials - Analog Devices AD8143-EVALZ User Manual

UG-862

BILL OF MATERIALS

Table 1. AD8143 Bill of Materials
Item Qty Reference Designator
1 19 R6, R7, R18, R24, R29, R32 to R35,
R39, R41 to R46, R51, R57, R58
2 3 R1, R20, R22
3 5 R36, R37, R48, R49, R52
4 2 R30, R31
5 6 R2 to R5, R12, R13
6 1 R50
7 2 C1, C2
8 4 C3, C5, C7, C8
9 3 C4, C11, C12
10 2 C10, C13
11 1 Z1
12 13 CINMA, CINMB, CINPA, CINPB,
INMB, INMG, INMR, INPB, INPG,
INPR, OUTB, OUTG, OUTR
13 4 GND1 to GND4
14 1 J1
15 1 P1
16 1 P2
17 1 SW1
18 1 VCC
19 1 VEE
20 4 C6, C9, C14, C15
21 1 CR1
22 17 R8 to R11, R21, R25 to R28, R38,
R47, R53, R55, R56, R59 to R62
23 3 R14, R19, R23
24 4 R15 to R17, R40
25 1 R54
26 2 R63, R64
27 1 Z2
AD8143-EVALZ/AD8145-EVALZ User Guide
Description
0, R0402
75, R0402
1k, R0402
30.1, R0402
49.9, R0402
475, R0402
10 μF, 3528
0.1 μF, C0402
0.01 μF, C0402
47 pF, C0402
AD8143, 32CSP5X5
SMACONRAA1, SMASMT
Test point, TP1
CON15_FEM, CONN_A012
RJ45
3-pin
SIP3
Test point, TP1
Test point, TP1
Variable, C0402
MAZ80470, SC76
Variable, R0402
Variable, 3299W
499, R0402
R0402
0, R0402
NL27WZ16, SOT23_6
Rev. 0 | Page 8 of 9
Manufacturer
Multicomp
Panasonic
Panasonic
Panasonic
Panasonic
Panasonic
AVX
Murata
TDK
Murata
Analog Devices, Inc.
Rosenberger
Keystone Electronics Corp.
TE Connectivity
TE Connectivity
Molex
Molex
Keystone Electronics Corp.
Keystone Electronics Corp.
Do not insert
Do not insert
Do not insert
Panasonic
Do not insert
Multicomp
ON Semiconductor
Part Number
0402WGF0000TCE
ERJ-2RKF75R0X
ERJ-2RKF1001X
ERJ-2RKF30R1X
ERJ-2RKF49R9X
ERJ-2RKF4750X
TAJB106K020RNJ
GRM155R71C104KA88D
C1005X8R1E103K
GCM1555C1H470JZ13D
AD8143ACPZ
32K243-40ML5
5006
1-1734530-1
RJ45-8X
22-11-2032
22-03-2031
5000
5004
Do not insert
Do not insert
Do not insert
ERJ-2RKF4990X
Do not insert
0402WGF0000TCE
NL27WZ16DFT2G
