Summary of Contents for Cal-Royal CR3000
- Page 1 C C AL-ROYAL CR3000 Digital Electronic Lock OWNER’S MANUAL...
- Page 2 THANK YOU for purchasing CAL-ROYAL CR 3000 Digital Lock. Your new CAL-ROYAL CR3000 Digital Lock advanced features include: 1 Master Code for entry including all other functions. 1 Sub-Master Code for entry and other programming functions. 10 Manager Codes for entry and other programming functions.
- Page 3 Connections: Batteries: Use only 1.5 volt AA batteries, 4 pieces. Low Battery: RED LED will flash five times with beep sound before BLUE LED flashes to signify acceptance of code. Batteries should be replaced as soon as this happens. Remote Switch/Release Options: The unit has 2 sets of terminals for remote release, labeled REM1 and REM2 on the printed circuit board.
- Page 4 The unit will emit 2 beeps with flashing BLUE and RED LED at the end of the anti-tamper period. CR3000 will exit the anti-tamper period, even within the 30 second duration, if the remote switch is activated (REM1 or REM2).
- Page 5 PROGRAMMING LIMITATIONS/SCHEDULE PROGRAM FUNCTIONS MASTER SUB-MASTER MANAGER USER SERVICE Unlock (Entry Only) Unlock and Enter Programming Mode Next Free Code Access Locator Code Location Function 011-015 Add Service Codes 021-025 Delete Service Code Delete All Service Codes Add/Change Manager Code or User Codes Deleting Manager or User Codes Disable 1 Manager or User Code Disable User Codes in 1 Bank...
- Page 6 Deleting a Manager Code: Program 2xx Manager Codes are located at locations 00, 10, 20, 30, 40, 50, 60, 70, 80 and 90 (see table 1A on page 11). [Current Master/Sub-Master Code] (#) (2) [2-digit Location Code] EXAMPLE: Assuming that the current Master or Sub-Master Code is (1) (2) (3) (4) (5) and you want to delete a Manager Code located at location 20. Press: (1) (2) (3) (4) (5) (#) (2) (2) (0) Manager Code at the specified location is deleted.
- Page 7 Disabling a User Code: Program 3xx User Codes are located at locations 01-09, 11-19, 21-29, 31-39, 41-49, 51-59, 61-69, 71-79, 81-89 and 91-99 (see table 1A on page 11). [Current Master/Sub-Master/Manager Code] (#) (3) [2-digit Location Code] EXAMPLE: Assuming that the current Master, Sub-Master or Manager Code is (1) (2) (3) (4) (5) and you want to disable a User Code located at location 21. Press (1) (2) (3) (4) (5) (#) (3) (2) (1) User Code at the specified location is disabled.
- Page 8 Enable User Codes in One Bank: Program 4x# This feature can be used by Master, Sub-Master or Manager Codes. Banks can only be enabled by the Manager in charge of his Bank. Master and Sub-Master can enable all Banks. [Master, Sub-Master, Manager Code] (#) (4) [1-digit Bank Number] (#) EXAMPLE: Assuming that the current Master, Sub-Master or Manager Code is (1) (2) (3) (4) (5) and you want to enable Bank1.
- Page 9 Delete Service Codes: Program 021, 022, 023, 024, 025 [Master, Sub-Master, Manager Code] (#) (0) [Service Code Number] EXAMPLE: Assuming that the current Master, Sub-Master or Manager Code is (1) (2) (3) (4) (5) and you want to delete Service Code 1. Press (1) (2) (3) (4) (5) (#) (0) (2) (1) Service Code 1 is now deleted.
- Page 10 Code Locator Function: Program 009 It is important to record all Codes in TABLE 1A for future reference. In the event of losing your records, this feature will help you locate as to where a certain Code is located in the lock’s memory. The unit will identify the Bank number (0-9) and User location (09) by flashing both the RED and BLUE LED accompanied by a beeping sound.
- Page 11 TABLE 1A MASTER SUB-MASTER BANKS MANAGERS USERS BANKS: Banks are designated group of locations in the lock’s memory. This lock has 10 banks (0-9) and each bank consists of 1 manager and 9 users under it. MANAGERS: 1 manager is assigned to each bank. There are 9 User Codes that each Manager can program in its bank. For instance, Manager “00”...
- Page 12 CAL-ROYAL is not liable of either the property or safety of the user’s family, employees, and limits its liability for any loss or damage including incidental or consequential to CAL-ROYAL’s original selling price of the product regardless of the cause of such loss or damage.
