Cal-Royal SC Series Installation Instructions

SC Series(SC8480)
�
Heavy Duty Mortise Lock
CAL-ROYAL
(Escutcheon Type)
PROOUCTS. INC .
Installation Instructions
A. Door Preparation
1. Measure desired
height from
finished floor,
mark a horizontal
Heigh!
line on door
line
and door edge.
2. Align template on edge of door
with applicable horizontal at
height line. Check the chart of
drilling trim holes on template
and mark only holes for lock
function being installed.
3. Mortise door edge according
to measurements of installation
template and drill proper holes
f o r trims.
4. Recess f o r face plate, the dimension
isLB-1/32" xWl-5/16" XD7/32".
B. Strike Installation
1 . Align strike template on jamb.
Be sure to keep 3/8" distance
between lock centerline and strike
centerline. Bore 1 " diameter holes
into door edge, 1-1/8" deep.
Recess 5/32 • for flush fit of strike
and dust box.
2. Mortise jamb according to
measurement of strike template.
Then fit strike and dust box into
frame and secure into place with
supplied screws.
C. Install Lock Case
A) Make sure lock hand to match door hand, use the f o llowing diagram
to determine the hand of door.
LH
Left Hand
:=L
._Q..;&._Jj
LHRB--' ...... ......
-.::::Ji
Left Hand
Reverse Bevel
--
7/32"
r·········•1
:
'
I :
:
j
: '
'
:
............ ,
'
Jamb�
. IT
-+P.-1.!__,. hoi<s
3-17/32"
INSIDE OF DOOR
Right Hand
'
c=>
OUTSIDE OF OOOR
INSIDE OF DOOR
c;:==?
: ��
b.
Right Hand
Reverse Bevel
OUTSIDE OF COOR
B ) Instructions for changing lock hand
1. Change latchbolt handing
If the hand of latchbolt doesn't match door hand, remove
fixing screw and pull latchbolt out from lock case, then tum
complete unit having the bevel of latchbolt to reverse door
handing. Position latchbolt back and fasten it.
Installation
template
2. Set outside hand of lock case
There are two SET SCREWS located at the bottom of the HUB,
one on each side. Remove the SET SCREW on the side facing
the secured side (outside or keysi de), and I eave the one facing
the interior side (inside)
•
.
'
f )
•
C) Check the hub of the lock if it is seated squarely with respect to
the body of the lo ck. Either arrow 1 or 2 on either side should
point directly t o the set screw.
1-1/S'deep
For LH & LHRB,
arrow 2 should
polntto the set
Remove this set screw
If this side Is facing the
outside of the door
If tha set screw Is ace Iden tally removed, f ollow procedures below to put It back.
RH
Spring plate
covering screw
hole
�
0
Pick the spring plate t � ush It aside
RHRB
and at the same time
the hub by using the splndle a couple
of degrees untll the spring plate Is
out of the way. Don't let go of the hub
whlleO Inserting the screw untll It Is
fully fastened.
Remove screw
Pull
out
IMPORTANT
For SC84El3 (Store Lock) F14 and
SC8010 (Passage) F01
SKIP THIS STEP
For SC808'2 Q nstitution) F3:J
REIVDVE SET SCREW
ON BOTH SIDES .
@
□
2
U
turn and hold
DRWG. # LSG-2020-10/22 -1 of 2
and
turn
For RH & RHRB,
, . . . . . . .. .. . © arrow 1 should
wrong@
position
