Summary of Contents for Stratasys J850

  • Page 4: Table Of Contents

    UV Lamps First Aid for Working with Printing Materials Contact with Skin Contact with Eyes Ingestion Inhalation Waste Disposal 3 Introducing the Stratasys J8 Series 3D Printer Work Configurations Source Files Printing Materials Storage Shelf Life Exposure to Light Safety Considerations...
  • Page 5 Advanced Settings 4-20 Keeping the Printer in Idle Mode 4-24 Shutting Down the Printer 4-25 Maintaining the Printer 4-28 Routine Maintenance Schedule 4-28 Maintenance Counters 4-29 UV Lamp Check 4-31 Pattern Test 4-31 Backing up the Printer Configuration 4-34 Improving Print Quality 4-34 Cleaning the Print Heads, Roller and Wiper 4-35...

  • Page 6: Using This Guide

    Using This Guide For More Information Terms Used in This Guide...
  • Page 7 This user guide provides instructions for installing, operating and maintaining J850/J835 3D printing systems. It explains how to use features, and provides practical examples to guide you as you use the system. The text and figures in this guide are based on the J8 Series 3D printer, software version 85.2.0.
  • Page 8 A build tray containing objects, each of which is designed to be printed using a different model material. Model Material used for building models. material Printer The computer inside the J850/J835 printer that operates it. computer Printer The GUI (graphical user interface) used for controlling J850/J835 interface printers.

  • Page 9: Safety Features

    Safety Features Symbols and Warning Labels Safety Guidelines Printer Installation Printer Operation UV Radiation Printer Maintenance Model and Support Materials UV Lamps First Aid for Working with Printing Materials Contact with Skin Contact with Eyes Ingestion Inhalation Waste Disposal...
  • Page 10 Stratasys 3D printers are designed to comply with CE and FCC standards. They are equipped with the following safety features: The power supplied to the UV lamp, the tray heater and the Interlock Switch motion motors is turned off when the cover is opened.
  • Page 11 Circuit Breaker The power to the printer is turned off in case of electrical overcurrent. Note: The circuit breaker is only accessible to service personnel. UV-Lamp Overheating The power supplied to the UV lamp and the motion motors is Protection turned off if the temperature around the lamp reaches 90°C (194°F).
  • Page 12 ➢ Leave a minimum of 15 centimeters (6 inches) between ventilation openings and walls or other objects. ➢ The printer should only be operated by persons trained by a Stratasys customer-support representative. ➢ All persons operating or maintaining the printer should know the location of first aid and emergency equipment and how to use it.
  • Page 13 ➢ Service operations should be performed only by qualified personnel who have been instructed in relevant safety precautions. ➢ Notify co-workers and those who have access to the printer before beginning non-routine and hazardous work. Model and Support materials are made of chemical substances. Although precautions must be taken when handling these materials directly, all Model and Support materials used by the printer are handled in sealed cartridges.
  • Page 14 UV lamps used by the printer to cure printing materials contain a small amount of mercury. In the unlikely event of lamp breakage, avoid inhaling mercury vapor, and ventilate the room. If the lamp ruptures (breaks) during operation, leave the room and ventilate it thoroughly for about 30 minutes. Use protective gloves to prevent contact with mercury and other lamp components.
  • Page 15 In general, try to avoid direct contact with uncured printing material. If skin or eyes come into contact with it, wash the area immediately and thoroughly with water, and follow these first-aid instructions. If uncured printing material comes in contact with skin, wash the affected area immediately and thoroughly with soap and cool water, then remove contaminated clothing.

  • Page 16: Printing Materials

    Vapors from printing materials can be irritating to the respiratory system. If respiratory irritation occurs, expose the victim to fresh air immediately. ➢ If the victim has stopped breathing, perform artificial respiration or cardiopulmonary resuscitation. ➢ Seek medical attention immediately. ➢...

  • Page 17: Storage

    Work Configurations Source Files Printing Materials Storage Shelf Life Exposure to Light Safety Considerations Disposal Work Environment Workstation Requirements...

  • Page 18: Producing Models

    J850/J835 printers offer the following options: • You can streamline and economize the process of producing models. ❒ Printing models made from different materials on the same build tray (“mixed tray”), in the same print job, eliminates the time-consuming need and expense of loading another material, flushing the system, and sending a separate job to be printed.
  • Page 19 The Stratasys J8 Series 3D printing system can be set up as a single-station system or as a multi-station system. When connected to a local computer network, the system can serve multiple users. In such configurations, each user (client) prepares files for production. A software service, installed on the printer computer, processes jobs and controls the printing.
  • Page 20 GrabCAD Print supports STL and, VRML files, and, in addition, native CAD formats from these programs: Creo, SOLIDWORKS, NX, CATIA and Inventor. To see the complete list of file formats supported by GrabCAD Print, go to: help.grabcad.com/print/file-formats. J850/J835 systems feature the capability of producing different types of model files simultaneously.
  • Page 21 • Support material—which fills gaps and spaces in the model during printing, and is removed after printing Materials used for printing models with J850/J835 printers are made of resins, which are composed of reactive monomers and oligomers. Although printing materials are supplied in sealed, UV-proof cartridges, care must be taken when storing and handling them.
  • Page 22 • 30%–70% relative humidity GrabCAD Print is an application for preparing and and managing print jobs on Stratasys J850/J835 printers (and on other supported 3D printers). To download GrabCAD Print, go to: help.grabcad.com/print/sign-up. To see the requirements for client computers running GrabCAD Print, go to: help.grabcad.com/print/system-requirements.
  • Page 23 Starting the Printer Loading Model and Support Cartridges Producing Models Preparing the Printer Starting Printing Printer Interface Color Key Printing Indicators Resuming Production After Printing has Stopped 4-10 Changing the Printing Material 4-13 Changing Model Materials Without Flushing 4-18 Advanced Settings 4-20 Keeping the Printer in Idle Mode 4-24...
  • Page 24 Replacing the Odor Filter 4-85 Replacing the UV Lamps 4-85 Dynamic Nozzle Test 4-91 Built-in Tests 4-92 Replacing the Waste Container 4-97 Cleaning the Exterior Panels 4-100 Cleaning the UV Screen 4-100...
  • Page 25   1. Turn on the main power switch, located at the back of the printer.
  • Page 26 2. After the printer-control computer boots, log in to Windows and launch the printer-control program: All monitoring and controlling of the printer is done from this interface.
  • Page 27 In High Mix / High Quality mode, J850/J835 printers use up to 14 cartridges of Model material and two cartridges of Support material, each weighing 4 kilograms when full. In Super High Speed mode, you can use four cartridges of Model material and four cartridges of Support material. A graphical...
  • Page 28 Models can be printed after they are arranged on a virtual build tray in the GrabCAD Print application. For information about preparing model files for printing, see the GrabCAD Print online documentation. Before beginning to produce models, it is recommended that you check the current printing quality of the print heads by performing a pattern test (see "Pattern Test"...
  • Page 29 Support material in the supply cartridges, printing proceeds automatically until the job is finished. The J850/J835 printer uses up to seven different Model-material cartridges to produce models. In addition, a Support-material cartridge is required. If additional cartridges are installed and they are not immediately needed for...
  • Page 30 printing, the printer interface indicates this (see "Printer Interface Color Key" below). The background colors in the printer indicator fields tell you at a glance whether or not the value or item is suitable or ready for printing. • Green—suitable/ready for printing For example, in Figure 4-4 on the previous page: ❒...
  • Page 31 The printer interface screen changes when you send a print job to the printer, if the printer is on line: • The mode changes from Pre-print to Printing. • The specific activity being performed is shown in the “current activity” field.
  • Page 32 If the printing process is interrupted, the print manager stops sending slices to the printer. This can happen, for example, if the printing material runs out in the middle of a print job, and you do not replace the empty cartridge immediately.
  • Page 33 4. In the job-preparation application, make sure that the correct slice number is entered in the dialog box. 5. If, for any reason, the correct number does not appear in the dialog box, enter the number and click You cannot continue printing the model if: •...
  • Page 34 1. Cancel the job in GrabCAD Print. In the Schedule screen: ❒ Right-click on the job to display the pop-up menu, and select OR— ❒ Left-click on the job to display the Job Status details, and click the Cancel icon 2.
  • Page 35 Before producing models using a different type of printing material than is currently installed, run the Material Replacement wizard to flush the print block and feed tubes. 1. Start the Material Replacement wizard from the Options menu. 2. In the opening screen, click 3.
  • Page 36 4. Choose the configuration for producing models: ❒ 7 Materials (High Mix / High Quality) ❒ 3 Materials (High Speed) ❒ Single Material (Super High Speed) 7 Materials Each print head is loaded with two different materials. You can print with any single material, or with a combination of them. High-speed printing is not available, but high-quality models can be printed.
  • Page 37 3 Materials Both sections of each print head are loaded with the same material. Up to three Model materials are available, with high-speed printing. Single Material Both sections of two print heads are loaded with the same Model material—DraftGrey (RGD750). Both sections of two print heads are loaded with Support material.
  • Page 38 7. For Support material, select the number of cartridges to replace. ❒ In High Mix / High Quality and High Speed modes, you can print using one or two Support cartridges. ❒ In Super High Speed mode, at least two Support cartridges are required;...
  • Page 39 10. Click to begin the material replacement process in the printer. The Cartridge Positioning screen appears, showing you the new location of all cartridges in the material cabinet. The correct cartridge is in this slot. No cartridge (or the incorrect cartridge) is in this slot. The cartridge in this slot has insufficient weight to complete the material replacement process.
  • Page 40 the job preparation application is also updated, and it displays the new material(s). 15. Inspect the area around the purge unit and clean it, if necessary. If you do not change the printing mode (High Quality/Speed) you can replace the Model materials without flushing out the current materials. Use this option when the color or mechanical properties of the printed model are unimportant.
  • Page 41 3. When the Material Replacement Options screen opens, select the Replace materials without flushing check box and click 4. In the confirmation message that appears, click to continue.
  • Page 42 5. In the Cartridge Positioning and Process Progression screen, click 6. Read the Warning message that appears, and click to continue. Material replacement begins. The Advanced Settings dialog box enables you to configure the Material Replacement wizard for special purposes. If necessary, click in the Material Replacement Options screen before clicking By default, Automatic slot selection determines the best slot locations for the cartridges in the material cabinet, based on materials currently in the system.
  • Page 43 1. In the Material Replacement Options screen, click 2. In the Advanced Settings screen, select , and click 3. In the Material Replacement Options screen, is selected for each position. To print with only one of the cartridges, clear the check box and then select either the left ( ) or the right ( ) cartridge.
  • Page 44 When printing in High Speed mode (three materials), the same material is used in both sections of each print head. The material selected for one of the cartridge slots is also used in the other print head channel. 4. After selecting the materials for the appropriate cartridge slots, the Cartridge Positioning screen appears.
  • Page 45 The flushing cycle you select in the Material Replacement Options screen determines how thoroughly to flush out material currently in the system. After selecting the Economy cycle and completing the wizard, you might decide that you require a more thorough flushing, to ensure accurate model color.
  • Page 46 Between printing jobs, the printer can be left unused for up to one week. If the printer will not be used for more than a week, use the Shutdown wizard to automatically perform the procedures that must be done before turning off the printer (see "Shutting Down the Printer"...
  • Page 47 You only need to shut down the printer if it will not be used for a week or more. Otherwise, the printer can remain on, in Idle mode. To properly shut down, the printer needs to perform several processes. These are controlled by the Shutdown wizard.
  • Page 48 3. Select the option corresponding to the length of time that the printer will not be used—less or more than 30 days. 4. In the next screen, verify that the tray is empty and click The shutdown procedure begins.
  • Page 49 5. Follow the instructions until cleaning is completed. 6. When the final wizard screen appears, close the printer-control application and shut down the printer computer. 7. After the printer computer shuts down, turn off the main power switch at the back of the printer (see Figure 4-2 on page 4-4).
  • Page 50 Performing routine maintenance tasks is essential for getting satisfactory results from J850/J835 printers. Perform the tasks at specified intervals.
  • Page 51 The printer computer application records the dates and frequency for each maintenance task. You can display the Maintenance Counters screen from the Options menu.
  • Page 52 If there is a maintenance task due, this is indicated on the main interface screen. If this indicator appears, you can display the Maintenance Counters screen by clicking on it. For maintenance tasks that are controlled by wizards, the dates and printing times are reset automatically when the relevant wizard is run and completed successfully.
  • Page 53 A heat-sensitive label is fixed to the UV lamp covers as a warning against overheating. Its center changes from white to black if the temperature of the cover reaches 65°C (150°F). If this occurs, do not use the printer, and call your service provider.
  • Page 54 5. Click in the Confirm dialog box to begin. 6. If the build tray is not clear, click in the following dialog box. This lowers the build tray, so that models on the tray are not damaged.
  • Page 55 The printer prints a series of lines on the test paper (see next figure). 7. Carefully inspect the test paper to see if there are missing lines. Too many missing lines, especially if they are in the same area, indicates that the quality of printing when producing models will be poor.
  • Page 56 It is recommended that you periodically back up the printer's configuration files. In case of printer malfunction or the need to re-install the software on the printer computer, parameters can be restored from the backup. The backup also saves the printer's log and the calibration and maintenance history.
  • Page 57 1. Carefully clean the print heads again, making sure there is no residue left on them. 2. Perform the purge sequence. 3. Perform the pattern test. ➢ Optimize the print heads and replace faulty print heads, if necessary (see "Optimizing (Calibrating) Print Heads" on page 4-51). Regular inspection and cleaning of the orifice plates on the bottom of the print heads prevents print nozzles from clogging.
  • Page 58 3. Make sure that the build tray is clear (empty), and close the cover. Confirm this in the wizard screen and click The printer moves components to the cleaning position. 4. When the following screen appears, open the printer. 5. Place the mirror on the build tray. 6.
  • Page 59 8. Clean the orifice plates, with a back-and-forth motion. Use the mirror to make sure that you have removed all of the residue material. 9. After cleaning the print heads, clean the entire roller surface, by rotating it as you clean. 10.
  • Page 60 13. Inspect the wiper. If the wiper is scratched, torn or worn, or if you cannot clean it completely, replace it. a. Grasp it and pull it up and out of its bracket. b. Insert the new wiper blade, making sure that it is straight and secured well on both sides.
  • Page 61 3. Remove the right UV-lamp assembly: a. Disconnect the UV power cable and the fan power cable. b. Remove the screw that secures the right UV lamp, and then pull and lift up the UV lamp. 4. Loosen the two screws securing the suction tube on the print block. 5.
  • Page 62 6. Remove the two screws securing the covering of the roller waste collector and remove it. 7. Remove the covering by pulling it out, and then lower it. 8. Clean the roller waste collector and the scraper blade surface using cotton swabs.
  • Page 63 6. Before returning the roller waste collector to the print block, make sure that the pins are clean. 1. Return the roller waste collector to the print block and screw on the covering (see Figure 4-46 on the previous page). 2.
  • Page 64 1. Prepare— ❒ a new roller scraper blade ❒ a Phillips 1x75 mm screwdriver ❒ a 2.5-mm and a 2-mm hex (Allen) key 2. Remove the right UV lamp and the roller waste collector covering (see steps 3 to 6 on page 4-39). 3.
  • Page 65 6. Place the new scraper blade onto the pins in the holder, as shown.
  • Page 66 7. Insert and tighten the roller scraper blade screws.   8. After tightening the screws, inspect the blade and make sure that it is straight. If necessary, loosen the screws and tighten them again, evenly. 9. Return the roller waste collector assembly and the right UV lamp to the print block.
  • Page 67 4. When the following screen appears, place the transparency on the build tray—next to the left and rear edges of the tray (see below). 5. Make sure that the transparency sheet is lying flat, and tape it to the tray. 6.
  • Page 68 When you click , the printer prints the head alignment test on the transparency. When printing is finished, the following screen appears. 9. Open the printer and remove the transparency. The transparency sheet is printed with sets of vertical lines in seven columns, each showing the results from a different print head.
  • Page 69 10. For each column of lines, use a magnifying glass or loupe to inspect pairs of consecutive rows printed on the transparency to see where the vertical lines align. Optimum head alignment is shown when the fourth lines in the upper and lower rows are aligned, as in Figure 4-60.
  • Page 70 13. Click to display the next head alignment screen, and again select the number representing the most closely aligned vertical lines on the transparency for that print head. When you have finished aligning all of the heads, the following screen is displayed.
  • Page 71 ❒ If the vertical lines for the print heads were not aligned at either extreme, choose End the wizard, then click To prevent excess printing material from accumulating around the print heads, a splash shield is installed on the bottom of the print block. Remove the shield and clean it once a month, when cleaning the print heads (see "Cleaning the Print Heads, Roller and Wiper"...
  • Page 72 4. Using a 2-mm hex (Allen) key, remove the screws to remove the splash shield. 5. Soak a cleaning cloth with 90% alcohol and clean the splash shield. 6. Return the splash shield to the print block and secure it with four (4) screws.
  • Page 73 The condition of the print heads directly affects the quality of printed models. To maintain optimum printing, you should routinely test the print heads, and calibrate them to the best working configuration possible by running the Head Optimization wizard every 300 hours of printing. You also need to calibrate the print heads after changing the printing mode between High Mix / High Quality and one of the high-speed modes.
  • Page 74 2. Start the Head Optimization wizard from the Options menu. 3. In the opening wizard screen, click to begin. The Wizard Conditions screen appears. 4. Read the conditions, select and click 5. In the following screen, select if you have recently cleaned the print heads.
  • Page 75 6. In the following screen, make sure Optimize all print heads is selected, and click 7. Select the printing mode for which you want to optimize the print heads and click...
  • Page 76 8. When the following screen appears, tape a sheet of pink paper to the surface left of the build tray, close the cover and click The printer prints a frame on the build tray and then prints the Pattern Test on the pink paper. 9.
  • Page 77 10. In the following wizard screen, enter the number of missing nozzles for each print head and click 11. The wizard continues according to the number of missing nozzles you entered. ❒ If there are too many missing nozzles for acceptable printing, the wizard instructs you to replace the defective print head(s).
  • Page 78 12. Set up the scale in the printer by performing the steps listed in the wizard screen. 13. After confirming all of the items listed in the wizard screen, click Printing material (resin) is jetted from each head and its weight is automatically recorded.
  • Page 79 16. When the following screen appears, remove the scale and clean the build tray. 17. In the wizard screen, confirm that the build tray is clear and that the cover is closed, and click The wizard uses the data collected to analyze the condition of the print heads and optimize them so they print models with a uniform layer of material.
  • Page 80 ❒ If the wizard determines that a print head is faulty—or that it is negatively affecting model quality with the current head configuration—you need to replace it. Indicate whether or not you want to do so now. • Select if you are prepared to replace the print heads now (see below).
  • Page 81 The condition of the print heads directly affects the quality of printed models. You may need to replace a print head if one or more of the following symptoms occurs: • The Head Optimization wizard determines that a print head is defective. (See "Optimizing (Calibrating) Print Heads"...
  • Page 82 1. Prepare— ❒ replacement print head(s) ❒ 90% isopropanol (IPA—isopropyl alcohol) or ethanol (ethyl alcohol) ❒ disposable cleaning gloves (supplied with the print head; or use any clean, powder-free protective gloves) ❒ a supplied cleaning cloth or equivalent ❒ a mirror ❒...
  • Page 83 6. In the following screen, select , and click 7. Select the print head(s) needing replacement, and click The printer heats and empties the print block, and prepares the printer. (This should take up to 15 minutes.) The following screen appears when the printer is ready for you to replace print heads.
  • Page 84 9. On the front of the print block, loosen the screws that secure the cover protecting the print-head driver cards. 10. Lift up the cover. 11. Loosen the screws that secure the driver-card bracket, and lower the bracket.
  • Page 85 12. Release the driver-card support. 13. Remove the driver card by releasing the latch at the points shown.
  • Page 86 14. Release the upper and lower screws that secure the print head in the block. (If necessary, you may use a 4-mm hex (Allen) key to loosen the screws.)
  • Page 87 15. Press down on the upper and lower locking screws to release the print head, and remove it from the bottom of the print block. 16. Make sure that along with the head, you remove the four (4) rubber O- ring seals.
  • Page 88 17. Place four (4) O-ring seals in the replacement head (see Figure 4-90 on the previous page). 18. Position the head in the print block, making sure that the location pins are in place. 19. Tighten the upper and lower screws that secure the print head in the print block (see Figure 4-89 on the previous page).
  • Page 89 22. In the Replace print heads screen, select the check box to confirm that you have replaced the head(s), and click 23. With your fingers, make sure that the new head is level and even with the other heads. 24. Confirm that the heads are level by selecting the check box in the following wizard screen, and click...
  • Page 90 25. In the next wizard screen, confirm that you have removed all tools and objects from the printer. 26. Close the printer cover. The wizard continues by heating the heads, then filling and purging them. If there are no installation problems, the optimization procedure begins, to calibrate the print heads to the best working configuration—see "Optimizing (Calibrating) Print Heads"...
  • Page 91 ➢ If the replacement head was not calibrated by Stratasys, remove the head and replace it with another one. Contact your Stratasys service provider about the uncalibrated head. The level of UV radiation from the lamps used for curing models can change over time.
  • Page 92 1. Start the UV Calibration Wizard from the Options menu. 2. In the following screen, select to adjust the lamp’s radiation level to the acceptable range. 3. In the following screen, select the UV sensor and measuring device to be used.
  • Page 93 4. Make sure that the build tray is empty. Confirm this in the wizard screen and click ➢ When using a Stratasys UV sensor box that you connect to the printer (TOL-03005-S), continue with "UV Sensor Connected to Printer" on the next page.
  • Page 94 The following steps apply when using the Stratasys UV sensor box that you connect to the printer. They do not apply when using a UV external radiation measuring device. 1. To synchronize the wizard and the UV sensor, enter the CF number from the label on the back of the UV sensor box.
  • Page 95 Continue with "UV Measurement " on page 4-75. The following steps apply when using a stand-alone UV meter. They do not apply when using the Stratasys UV sensor box connected to the printer. 1. When the following screen appears, open the printer and place the UV...
  • Page 96 2. Lead the cable out of the printer so that you can close the printer, and tape it down to make sure that it does not interfere with the moving print block. 3. Close the printer, while checking that the sensor does not move out of position.
  • Page 97 The UV lamps power up and stabilize. (This takes several minutes.) Then, the print block passes over the sensor and the wizard compares the measured radiation to the recommended level for each UV lamp and printing mode. During this process, which takes 20–40 minutes, you need to monitor the progress as displayed in the wizard screen.
  • Page 98 1. Click 2. Remove the UV sensor and close the printer cover. After confirming the items listed in the wizard screen, click If the results are not acceptable for quality printing, this is indicated in the final wizard screen. 3. In the final wizard screen, click Load cells are sensors that measure the weight of the material cartridges and the waste container in the printer.
  • Page 99 4. In the next wizard screen, observe the numbers and wait until the weight level is relatively stable—two units above or below the average level shown. 5. Select the check box, and click 6. Click in the final wizard screen.
  • Page 100 The tubes that pump waste material from the roller waste collector and the purge unit should be replaced after 1500 hours of printing. At this time, a counter should display a maintenance message on the printer interface screen. You can verify that the pump tubes need to be replaced by examining the waste pump maintenance counters.
  • Page 101 To replace pump tubes, you replace the "cassette" assembly that attaches to the pump in the printer. Replacement cassettes are supplied in the printer Start-up Kit. Additional cassettes can be ordered from your Stratasys service provider. 1. Make sure that the printer is in Idle mode (see the figure on page 4-4).
  • Page 102 3. Open the panel and disconnect the ground (earth) wire. 4. Remove the panel. 5. Identify the waste pump that requires tube replacement.
  • Page 103 6. Unscrew the fittings that connect the waste tubes to the pump. 7. Remove the part of the fitting remaining on the pump tube, and save it. 8. When the tubes on both sides of the pump are disconnected, rotate the pump "cassette"...
  • Page 104 Filters are installed in the lines that supply Model material to the print heads. To ensure that the heads remain in optimum condition, the filters are replaced by your service provider, as part of the scheduled maintenance routine. However, filters used for certain materials need to be replaced more often.
  • Page 105 3. Shut down the printer computer, wait 60 seconds after the monitor goes blank, and turn off the main power switch. 4. Using an 8-mm hex (Allen) key, open the two latches that secure the back of the materials cabinet and remove the back of the cabinet. 5.
  • Page 106 10. Identify the inlet side of the new filter. This is the side showing the part number. A 6mm tube is connected to the inlet. (An 8mm tube is connected to the outlet.) 11. Attach the inlet side of the new filter to the disconnected tube. 12.
  • Page 107 17. In the Maintenance Counters screen, click and then (see Figure 4-122 on page 4-82). If the printer exhaust is not connected to an external ventilation system, a built-in activated-carbon filter removes odors from printing materials. This filter should be replaced regularly (as necessary) to keep your working environment pleasant.
  • Page 108 3. Make sure that the build tray is empty, and confirm this in the wizard screen. Then, close the printer, and click The axes move to the “home” position. 4. Select the UV lamp(s) to be replaced and click 5. Disconnect the UV-lamp power connector and the UV heat fuse connector.
  • Page 109 6. Loosen the screw securing the UV lamp cover (A), and pull the cover up (B), then out (C). 7. Pull the UV lamp reflector out of the UV housing. 8. Inspect the new UV lamp reflector, and make sure that a black strip is attached to the inside of it.
  • Page 110     10. Insert the new UV lamp/reflector unit into the housing, next to the print block. 11. Replace the UV lamp cover by inserting it into the slot on the bottom of the housing, and tighten the securing screw on top.
  • Page 111 12. Reconnect the power and heat fuse connectors. 13. In the wizard screen, confirm that you have replaced the UV lamp(s) and that the black strip is attached, then click The wizard operates the UV lamps and checks if their power is within the acceptable range for each printing mode.
  • Page 112 After replacing a UV lamp, it is recommended that you calibrate its power for the various printing modes. The next screen allows you to continue to the UV Calibration wizard (see "Testing and Calibrating the UV Lamps" on page 4-69).
  • Page 113 ❒ In the right sample shown above, there are only two gaps, which is acceptable. Many gaps in the sample indicates that many nozzles in the print head are not functioning. This might indicate the need to replace the defective head. In this case, consult with your Stratasys service provider.
  • Page 114 The printer application contains a suite of tests for regularly checking the hardware and software, and for troubleshooting. Because running the tests affects the operation of the printer, you can only open the Built-in Tests interface when the system is not printing. The test suite features: •...
  • Page 115 The Built In Tests screen lists pre-configured tests, grouped by component categories. In this screen, you select and run tests, and the results are displayed. Test Name This column lists all of the tests, together with selection check boxes. Click the check boxes to select the tests you want to run. To remove a selection, click the check box again.
  • Page 116 Test Selection Area In the Test Selection area, at the bottom of the screen, you can quickly select or de-select tests by their characteristics: ➢ Click ➢ Use the Save and View command buttons. Click the command buttons, on the right side of the screen to perform the following operations: Click to run the selected tests.
  • Page 117 Status column. The following table lists the name of each test in the Built-in Tests suite, together with its description and a possible reason for its failure. If you need assistance, contact your Stratasys service provider.
  • Page 119 Printer waste contains partially cured polymeric material, collected during normal operation and maintenance of the printer. For safety and environmental reasons, this material is kept in a special leak-proof, disposable container. The container has a capacity of 10 kilograms of waste material—usually enough for several months of printer use.
  • Page 120 The waste container consists of a plastic container inside a cardboard box. You typically dispose of the entire waste container—including the box. Therefore, you must assemble a new box and insert a new plastic container before you can install it in the printer. 1.
  • Page 121 9. Close the waste compartment door.
  • Page 122 The painted exterior plastic panels of the printer has a durable finish, offering excellent chemical resistance to common cleaning materials. Follow the recommendations below when cleaning these areas of the printer. Acceptable Cleaning Agents • mild soap solution • common household cleaners and window cleaners •...
  • Page 124 Removing Models After Printing Removing the Support Material Post-Printing Treatment for Models Made with VeroClear 5-5 Photo-Bleaching Instructions Storing Models...
  • Page 125 After printing models, you should allow them to cool as much as possible before handling them. If additional models do not have to be produced on the printer, it is best to let the printed models cool in the printer, with the cover closed, as long as possible.
  • Page 126 For most models, the most efficient way to remove Support material is by using a high-pressure water jet. One suitable system is the Balco WaterJet cleaning unit. This device is marketed by Stratasys. To clean a model using this device, you place it in the chamber, and you manipulate it and the jet using the built-in, waterproof sleeves.
  • Page 127 Soak models in a 1-percent solution of caustic soda (sodium hydroxide) to remove Support material from difficult-to-reach areas and to give the model a smooth, clean finish. The amount of time you soak the model in the solution depends on how delicate it is and how much Support material needs to be removed, but it is typically between half-an-hour and several hours.
  • Page 128 ❒ For parts with a glossy finish, continue the photobleaching treatment for up to 18 hours more. In Stratasys laboratories, there was a tint reduction of approximately 70% within six hours. After 24 hours, tint was reduced by approximately 90%.
  • Page 129 Models are cured as they are printed, making them safe and stable for a long time. However, proper storage conditions are necessary to prevent deforming. • Keep printed models at room temperature and in a low-humidity environment. • Do not expose models to direct sunlight and other heat sources.
