Parotester2 – supply of the barcode
reader
The barcode reader is supplied with an RS
232 cable, Velcro-type fastener and holders,
already programmed and ready for use. To
prevent incorrect parameter transfer during
protocol transfer of the barcode reader, all
transfer parameters are integrated in this sheet
in the form of a barcode (items 1 to 14).
Procedure for a new barcode reader
parameter setting.
The barcode reader must be connected to the
Parotester2 display device. The display device
is switched on.
Scan items 1 to 14 with the laser in turn
continuously without removing the reader.
The programming mode must be concluded
with item 14.
The barcode reader is once more correctly
programmed and ready for use.
© 2012 Proceq SA
Technical data of the barcode reader
ON / OFF
Program mode
1
Type:
2
Dimensions:
Voltage:
3
Current during scanning: 135 mA, typically @ 5
4
5 Laser class:
6
Light source:
7
Laser power :
Interface:
8
9
Minimum module width: 0.173 mm (6.8 mil)
Scanning speed:
10
Scanning pattern:
11
Depth of the scanning
field:
12
13
Width of the scanning
field:
14
ON / OFF
Program mode
Operating temperature:
Moisture:
IS4225
45.7 mm x 40.6 mm x 18.5 mm
5 VDC ± 0.25 V
VDC
CDRH: Class II and IEC
Class II component
650 nm
0.75 mW (peak)
RS 232
52 scan lines per second
One scanning line
12.7 mm – 203 mm for 0.33 mm
(13 mil) barcodes
28.6 mm @ direct contact;
101.6 mm @ 76.2 mm
-20 °C to 50 °C
5% to 95 % relative
air humidity
(non-condensing)
