AC EXCEPTION VOLTAGE
SIMPLE LOGGER
Model L215
SPECIFICATIONS
MODEL
ELECTRICAL
Number of Channels
Measurement Range
Input
Input Connection
Resolution
Accuracy
Sample Rate
Storage Technique
the oldest. Recording only occurs during alarm conditions.
Data Storage
Output
Indicators
Controls
Power Source Powered from measured signal with 9V Alkaline battery backup
Battery Life
MECHANICAL
Dimensions
Weight
Case Material
Mounting
ENVIRONMENTAL
Operating Temperature
Storage Temperature
Relative Humidity
SAFETY
Safety Rating
Double Insulation
Technical Assistance (800) 343-1391
®
Model L215
L215
One
0 to 250Vrms
250V, Programmable event window
Recessed safety banana jacks on
10 bit, 250mV max
±1% of Reading + 250mV
36,000/hr (10 samples per sec)
Exception recording in FIFO mode; 60 samples stored
when alarm is tripped. Each 60 second sample recording
is considered to be a packet. When memory is full, data
will be overwritten one packet at a time beginning with
73,620 readings
RS-232 via DB9 connector (@ 4800 baud)
Red LED double flashes in LOGGING, single flashes
in STANDBY, and is off in OFF mode. Amber LED single
flashes for Exception and can only be reset
by stopping the recording and downloading the data.
One button used to start and stop recording sessions
and to turn the data logger on and off
Up to one year of recording @ 77°F (25°C)
2.88 x 2.32 x 1.62" (73 x 59 x 41mm)
5 oz (140g) including battery
Polystyrene UL VO
Base plate mounting holes or Velcro
-4° to 158°F (-20° to 70°C)
-4° to 174°F (-20° to 80°C)
5 to 95% non-condensing
EN 61010, 300V Cat. III
Yes
The AC Exception Voltage Simple Logger
Model L215 is the ideal product to capture
short-term events such as sags and swells.
This logger samples the input 10 times per
second and only stores the data when an
alarm threshold is crossed, thus maximizing
its use of memory. The 73,000-point storage
capacity provides enough memory to store
more than 1000 events, each containing
60 data points. The Model L215 is powered
by the AC voltage signal it is monitoring
and incorporates a backup battery to
provide up to one year of additional
operation and data storage protection.
FEATURES
3 / " (19mm) centers
4 APPLICATIONS
® pads
Model L215 monitoring a control panel looking for
dropouts and spikes in the line voltage
0 to 250Vrms measurement range
10 samples per second
Stores data when alarm level is tripped
True RMS measurements
Stores over 73,000 readings
10 bit resolution (250mV)
Detect sags and swells
Scale automatically selected by software
Software programmable High and Low
alarm levels
RS-232 output
One button operation
Alarm trip LED indicator
Surge/Sag monitoring
Computer room monitoring
Residential monitoring
Machine monitoring
Marine power monitoring
And many more
®
