THERMOCOUPLE
SIMPLE LOGGER
Models L610, L620 & L630
SPECIFICATIONS
MODELS
ELECTRICAL
Number of Channels
Measurement Range
Input
Input Connection
Resolution
Accuracy
Sample Rate
Storage Technique
Data Storage
Output
Indicators
Controls
Power Source
Battery Life
MECHANICAL
Dimensions
Weight
Case Material
Mounting
ENVIRONMENTAL
Operating Temperature
Storage Temperature
Relative Humidity
SAFETY
Safety Rating
Double Insulation
10 www.aemc.com
®
Model L630
L610
One
32° to 1382°F (0° to 750°C)
J thermocouple
Miniature black thermocouple jacks
12 bit
Red LED flashes once every two seconds in STANDBY mode, twice every two seconds
One button used to start and stop recording sessions and to turn the data logger on and off
The Simple Logger
and L630 are single channel, low cost
thermocouple data loggers that require
no user setup. They have the ability to
automatically adjust both their scale range
and their sample rate to optimize the
recording session.
FEATURES
APPLICATIONS
L620
One
-328° to 2282°F (-200° to 1250°C)
K thermocouple
Miniature yellow thermocouple jacks
12 bit
0.5% of Reading + T/C Accuracy
4096/hr max
Time Extension Recording
16,384 readings
RS-232 via DB9 connector
in LOGGING mode, and is off in OFF mode
9V Alkaline battery
Up to one year of recording @ 77°F (25°C)
2 .88 x 2.32 x 1.62" (73 x 59 x 41mm)
5 oz (140g) including battery
Polystyrene UL VO
Base plate mounting holes or Velcro
-4° to 158°F (-20° to 70°C)
-4° to 174°F (-20° to 80°C)
5 to 95% non-condensing
EN 61010, 30V Cat. III
Yes
Technical Assistance (800) 343 -1391
® Models L610, L620
Three models to choose from:
Model L610 (Type J)
32° to 1382°F (0° to 750°C)
Model L620 (Type K)
-328° to 2282°F (-200° to 1250°C)
Model L630 (Type T)
-328° to 662°F (-200° to 350°C)
Inputs via color-coded miniature
thermocouple jacks
Open thermocouple
RS-232 output
One button operation
Internal cold junction compensation
Accuracy: ±0.5% of Reading + T/C Accuracy
Process control monitoring
Wave soldering
Refrigeration monitoring
HVAC
And many more
L630
-328° to 662°F (-200° to 350°C)
T thermocouple
Miniature blue thermocouple jacks
12 bit
™ (TXR ™ )
® pads
One
