  • Page 1 User Manual ENGLISH AC/DC Current Oscilloscope Probe Model SL261 CURRENT PROBES WITH AEMC INSTRUMENTS ®...
  • Page 2 Copyright Chauvin Arnoux , Inc. d.b.a. AEMC Instruments. All rights reserved. © ® ® No part of this documentation may be reproduced in any form or by any means (including electronic storage and retrieval or translation into any other language) without prior agreement and written consent from Chauvin Arnoux , Inc., as governed by United States and International copyright laws.
  • Page 3 For recalibration, please use our calibration services. Refer to our repair and calibration section at www.aemc.com/calibration. Serial #: Catalog #: 1201.51 Model #: SL261 Please fill in the appropriate date as indicated: Date Received: Date Calibration Due: Chauvin Arnoux , Inc. ®...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS 1. INTRODUCTION ..............5 1.1 INTERNATIONAL ELECTRICAL SYMBOLS ......5 1.2 DEFINITION OF MEASUREMENT CATEGORIES ....5 1.3 PRECAUTIONS FOR USE ..........6 1.4 RECEIVING YOUR SHIPMENT ..........6 1.5 ORDERING INFORMATION ............. 6 1.5.1 Accessories and Replacement Parts ......... 6 2.

  • Page 5: Introduction

    Example: hardwired equipment in fixed installation and circuit breakers. CAT II: Corresponds to measurements performed on circuits directly connected to the electrical distribution system. Example: measurements on household appliances and portable tools. AC/DC Current Oscilloscope Probe Model SL261...

  • Page 6: Precautions For Use

    (10 A-100 mV/A, 100 A-10 mV/A, BNC) .......... Cat. #1201.51 Includes a user manual. 1.5.1 Accessories and Replacement Parts Adapter - BNC Adapter for use with AC/DC Current Probe Model SL261 & Meters 8220, 8333, 8335 & 8336 ......Cat. #2140.40 AC/DC Current Oscilloscope Probe Model SL261...

  • Page 7: Product Features

    2 meter coaxial cable with an insulated BNC. 2.2 COMPATIBILITY The Model SL261 is compatible with any analog or digital oscilloscope or other voltage-measuring instrument which has the following features: ■ BNC input connector ■...

  • Page 8: Specifications

    10 mV/A: 0.01 Ω Rise or Fall Time: Range 100 mV/A: 3 µs Range 10 mV/A: 4 µs Working Voltage: 600 V Common Mode Voltage: 600 V Influence of Adjacent Conductor: < 0.2 mA/A AC/DC Current Oscilloscope Probe Model SL261...

  • Page 9: Mechanical Specifications

    (10 to 30) °C: 85 ± 5 % RH (without condensation) (40 to 50) °C: 45 ± 5 % RH (without condensation) Influence of Temperature: < 0.2 % per °C Altitude: Non-operating: (0 to 12,000) m Operating: (0 to 2000) m AC/DC Current Oscilloscope Probe Model SL261...

  • Page 10: Safety Specifications

    EN 50081-1 Class B EN 50082-2 Electrostatic discharge IEC 1000-4-2 ƒ Radiated Field IEC 1000-4-3 ƒ Fast Transients IEC 1000-4-4 ƒ Magnetic Field at 50/60 Hz IEC 1000-4-8 *Specifications are subject to change without notice AC/DC Current Oscilloscope Probe Model SL261...

  • Page 11: Typical Response Curves

    10 mV/A frequency response measurement current: 1A sine Frequency 10000 phase in ° 100000 Frequency in Hz range 10 mV/A -100 phase graph measurement current: 1A sine -150 range 100 mV/A Phase Shift AC/DC Current Oscilloscope Probe Model SL261...
  • Page 12 Typical Specification -10% -12% -14% -16% 100A Accuracy AC/DC Current Oscilloscope Probe Model SL261...

  • Page 13: Operation

    WARNING: Always connect the probe to the instrument before clamping onto the circuit under test. Connect the Model SL261 to the proper input channel on the oscilloscope. ■ Begin with the least sensitive range on the current probe (10 mV/A).

  • Page 14: Maintenance

    ƒ Disconnect the probe from the circuit and the oscilloscope. ƒ Turn the probe OFF. ƒ Unscrew the battery compartment screw and pull out the battery compartment cover. ƒ Replace the battery and put the cover back on. AC/DC Current Oscilloscope Probe Model SL261...

  • Page 15: Repair And Calibration

    Chauvin Arnoux , Inc. d.b.a. AEMC Instruments ® ® Phone: (800) 343-1391 (Ext. 351) Fax: (603) 742-2346 E-mail: techsupport@aemc.com www.aemc.com AC/DC Current Oscilloscope Probe Model SL261...

  • Page 16: Limited Warranty

    (603) 749-6434 (Ext. 360) Fax: (603) 742-2346 E-mail: repair@aemc.com Caution: To protect yourself against in-transit loss, we recommend that you insure your returned material. NOTE: You must obtain a CSA# before returning any instrument. AC/DC Current Oscilloscope Probe Model SL261...
  • Page 17 NOTES:...
  • Page 18 NOTES:...
  • Page 19 NOTES:...
  • Page 20 12/23 99-MAN 100042 v19 AEMC Instruments ® 15 Faraday Drive • Dover, NH 03820 USA Phone: +1 (603) 749-6434 • +1 (800) 343-1391 • Fax: +1 (603) 742-2346 www.aemc.com © 2003 Chauvin Arnoux , Inc. d.b.a. AEMC Instruments. All Rights Reserved. ®...
