AEMC instruments SIMPLE LOGGER L100 Quick Start Manual page 12

FLEXIBLE CURRENT
PROBE SIMPLE LOGGER
Models AL24-2500,
AL36-2500, AL24-5000
& AL36-5000
SPECIFICATIONS
MODELS
ELECTRICAL
Number of Channels
Measurement Range
Internally Switch Selectable
Input Sensor
Resolution 250A
500A
2500A
5000A
Accuracy
Storage Technique
Data Storage
Output
Indicators
Controls
Power Source
Battery Life
MECHANICAL
Sensor Diameter
Logging Module Dimensions
Weight
Case Material
Mounting
ENVIRONMENTAL
Operating Temperature
Storage Temperature
Relative Humidity
SAFETY
Safety Rating
Double Insulation
12 www.aemc.com
Model AL36-5000
AL24-2500 AL36-2500
One
5 to 250Arms or
5 to 2500Arms
24" AmpFlex ™
1A max
–
10A max
–
Red LED light flashes once every two seconds in LOGGING mode, and is off in OFF mode.
One button used to start and stop recording sessions and to turn the data logger on and off
The AmpFlex
Loggers
become the ultimate measurement recording
®
device. The AmpFlex
is designed to take measurements where
standard clamp-ons cannot: in tight breaker
panels, around large bus bars, around cable
bundles and even wrapped around irregular
shapes. Combined with the recording
technology of the Simple Logger
records and graphs True RMS readings. The
flexible sensor is available in 24" and 36". It
is weatherproof NEMA 4X, IP65 rated. The
flexible current probe logger is self-contained
and records for up to six months.
FEATURES
APPLICATIONS
AL24-5000
One
5 to 250Arms or
5 to 2500Arms
36" AmpFlex ™
1A max
–
10A max
–
1% of Reading + Resolution
Time Extension Recording
8192 Readings
RS-232 via 5 pin circular connecter
LED is on continuously in overload condition
9V Alkaline battery
Up to six months of recording @ 77°F (25°C)
0.5" (12.5mm)
4.5 x 2 .5 x 1.56 " (114 x 64 x 41mm)
15.5 oz (439g) including battery
ABS UL94 VO
Velcro ® pads supplied loose
-4° to 158°F (-20° to 70°C)
-4° to 174°F (-20° to 80°C)
5 to 95% non-condensing
EN 61010, 30V Cat. III
Yes
Technical Assistance (800) 343 -1391
™ Flexible Current Probe Simple
® combine two technologies to
™ flexible current probe
Four models to choose from
True RMS recording —
250 and 2500Arms/500 and 5000Arms
Self contained, no exposed connections
Weatherproof NEMA 4X, IP65 rated
Flexible sensor — fits anywhere
Records for up to six months
Scale automatically selected
in software
RS-232 output
Load profiling
Machine load monitoring
Substation monitoring
AL36-5000
One
5 to 500Arms or
5 to 5000Arms
24" AmpFlex ™
–
2A max
–
20A max
™ (TXR ™ )
® it measures,
One
5 to 500Arms or
5 to 5000Arms
36" AmpFlex ™
–
2A max
–
20A max
