DESCRIPTION
9 6 5 Output AUX 1/2 contact
9 6 6 Force Hp Heat
9 6 7 Force Hp Cool
9 6 8 Force WHB
9 6 9 Anode output
9 7 Test & Utilities
9 7 0 Air-purge function
9 7 1 Floor drying cycle
9 7 2 Floor drying total Remaining Days
9 7 3 Floor drying functional Remaining Days
9 7 4 Floor drying curing Remaining Days
9 8 Energy Manager Statistics
9 8 0 HP Heating Running hours (h/10)
9 8 1 HP+Boil both ON running hours (h/10)
9 8 2 HP On cycles (n/10)
9 8 3 HP Defrost hours (h/10)
9 8 4 Cooling running hours (h/10)
9 8 5 Heating running hours (h/10)
9 8 6 DHW running hours (h/10)
9 9 Energy Manager Info
9 9 0 kWh cost from HP Actual
9 9 1 kWh cost from Boiler Actual
9 9 2 kWh cost from HP Estimated
9 9 3 kWh cost from Boiler Estimated
9 10 HP Diagnostics - 1
9 10 0 Outside air temperature
9 10 1 HP water fl ow temp
9 10 2 HP water return temp
9 10 3 HP Evaporator temp
9 10 4 HP Suction temp
9 10 5 HP Discharge temp
9 10 6 HP condenser outlet temp
9 10 7 Flow Switch
9 10 8 HP Actual Compressor frequency
9 10 9 HP Set Compressor Modulation
9 11 HP Diagnostics - 2
RANGE
OFF - ON
OFF - ON
OFF - ON
OFF
MIN
MAX CH
MAX DHW
OFF - ON
OFF - ON
OFF
Functional Heating
Curing Heating
Functional Heating + Curing Heating
Curing Heating + Functional Heating
Manual
OPEN
CLOSE
FACTORY SETTINGS
OFF
OFF
OFF
OFF
OFF
OFF
OFF
read only
read only
read only
read only
read only
read only
read only
read only
read only
read only
read only (Euro/cent.)
read only (Euro/cent.)
read only (Euro/cent.)
read only (Euro/cent.)
read only (°C)
read only (°C)
read only (°C)
read only (°C)
read only (°C)
read only (°C)
read only (°C)
read only
read only (Hz)
read only (%)
