Summary of Contents for ACME Diamonds II

  • Page 2: Table Of Contents

    CONTENTS 1. Safety Instructions ....................2 2. Technical Specifications ..................4 3. Control Panel ......................5 4. How To Set The Unit ....................6 5. How to Control the Unit..................10 6. Control By Universal DMX Controller ..............11 6.1 DMX512 Connection ..................11 6.2 Address Setting ....................

  • Page 3: Safety Instructions

    1. Safety Instructions Please read the instruction carefully which includes important information about the installation, usage and maintenance. WARNING Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Please keep this User Guide for future consultation.
  • Page 4  Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit.  It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.  Minimum ambient temperature TA: 0℃. Maximum ambient temperature TA: 40℃.
  • Page 5  DO NOT open the unit as there are no user serviceable parts inside.  Never try to repair the unit by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please contact the nearest authorized technical assistance center if needed.

  • Page 6: Technical Specifications

    2. Technical Specifications Power Voltage: 100-240V~ 50/60Hz Power Consumption: 185W Light Source: 10W RGB Beam Angle: 30° Dimmer/Shutter: Smooth dimming from 0-100%; outstanding strobe effect with variable speed Control: DMX Channel:：27 / 52 CH Control Mode: Voice CONTROL/SELF-WALKING/DMX512/Master/Slave/ILDA Construction: Display: OLED Data In/Out: 3-pin (5-pin XLR is optional) Power In/Out: Power Connector in/out Protection Rating: IP20...

  • Page 7: Control Panel

    Suitable for clubs, bars, nightclubs, TV stations, advertising promotion and other places The chassis adopts dustproof design, follows the classic double-layer design, the enclosure of the chassis is better, can effectively insulate the lampblack of the bar Lightweight, easy to transport and hanging lights, high brightness, color unity. 尺寸/重量：...

  • Page 8: How To Set The Unit

    1. POWER SWITCH: Turn Power On/off 2. KNOB 3. Power Input (POWERCON version) : connect power supply 4：EASY ILDA 5. Screen: Liquid Crystal Display 6. Ilda interface 7. DMX INPUT: For DMX512 connections, use a 3-core XLR signal line to connect the lamp to the DMX console, and enter DMX signal (optional) 8.
  • Page 9 Animation ON/OFF Repeat ON/OFF ONE / FILE / ALL Music ON/OFF SD card Mode Directory File 1/48 Test Mode Image 1-3 Channel Setting 27CH / 52CH Master / Slave ON/OFF Scan-safety ON/OFF EASY ILDA ON/OFF Language CH/EN System Sound Sense 0-100 Setting Channel Num Operational Mode...
  • Page 10 DMX Addresses To select DMX Addresses，Press the ENTER button to confirm that the current mode will be displayed on the display, use the UP/DOWN button to select the DMX entry address, use the Knob to find the start address (001-512) , and then press the Knob to confirm and set.
  • Page 11 1.The native system can read the SD card 8 already fixed folder, each folder can read 48 pattern file, pattern file format (. ILD) format file. The UP/DOWN button allows you to select a pattern file. If the looping is set to ON, the entire SD folder will be looped. (single file name selection is invalid.) If you want to select a single file name, you need to return the looping to OFF.
  • Page 12 (3). Folder and content play sequence as following The files in folder will be played in the order in which the files are copied to the SD card. That is, the first copied, first play. If you want to change the play sequence, you can copy them in the sequence you want.

  • Page 13: How To Control The Unit

    Master Setting To select Master Setting，Press the ENTER button to confirm that the current mode will be displayed on the display, use the UP/DOWN button to select: Color ,Scan Brightness,Design , Invert X ,Invert Y , press the Knob to confirm. Go back to the main menu and select exit.

  • Page 14: Control By Universal Dmx Controller

    6. Control By Universal DMX Controller 6.1 DMX512 Connection 1. At last unit, the DMX cable has to be terminated with a terminator. Solder a 120-ohm 1/4W resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug and plug it in the DMX-output of the last unit.

  • Page 15: Address Setting

    6.2 Address Setting If you use a universal DMX controller to control the units, you have to set DMX address from 1 to 512 so that the units can receive DMX signal. Press the MENU button to enter menu mode, select DMX Settings, press the ENTER button to confirm, use the UP/DOWN button to select DMX Address, press the ENTER button to confirm, the present address will blink on the display, use the UP/DOWN button to adjust the address from 001 to 512, press the ENTER button to store.
  • Page 16  DMX-512 channel CH1=32-63, CH2 - CH27 or CH2 - CH52 valid CH1=64-127, CH2, CH6 valid Channel Parameter Value Parameter description Black 0～31 Manual play 32～63 IPLAY mode Auto play 64～95 Music play 96～127 Manual play 128～159 Auto play 160～191 SD mode Music play (one file) 192～223...
  • Page 17 Macro 6 208～223 Macro 7 224～239 Macro 8 240～255 CH18 CH43 Write in Visible point 100%-0 0～255 Invalid 0～15 16~31 Macro 1（valid for 14CH 25CH ） 32~47 Macro 2（valid for 14CH 25CH ） 48~63 Macro 3（valid for 14CH 25CH ） 64~79 Macro 4（valid for 14CH 25CH ）...
  • Page 18 Macro 3 85～126 Strobe Slow... fast 127～255 Invalid Macro 1 1～32 Macro 2 33～64 Macro 3 65～96 CH22 CH47 X position Macro 4 97～128 Macro 5 129～160 Macro 6 161～192 Macro 7 193～224 Macro 8 225～255 Invalid Macro 1 1～32 Macro 2 33～64 Macro 3...
  • Page 19 Macro 2 33～64 Macro 3 65～96 Macro 4 97～128 Macro 5 129～160 Macro 6 161～192 Macro 7 193～224 Macro 8 225～255 Invalid Macro 1 1～32 Macro 2 33～64 Macro 3 65～96 CH26 CH51 X flip Macro 4 97～128 Macro 5 129～160 Macro 6 161～192...
  • Page 20 SD card 20CH Channel Parameter Value Parameter description Black 0～31 Manual play 32～63 IPLAY mode Auto play 64～95 Music play 96～127 Manual play 128～159 Auto play 160～191 SD mode Music play (one file) 192～223 Music play (all files loop) 224～255 Dimmer Brightness 0% ..
  • Page 21 Default 0～31 White 32～63 64～95 Yellow 96～127 CH17 Color Green 128～159 Cyan 160～191 Blue 192～223 Purple 224～255 CH18 Write in Visible point 100%-0 0～255 Default 0～15 CH19 Speed 16~31 Pause 32~255 25% - 200% Default 0～31 CH20 Scan rate 6k - 29k 32～223 224～255...

  • Page 22: Troubleshooting

    7. Troubleshooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connect power. 2. Measure the mains voltage on the main connector. 3.
  • Page 24 Innovation, Quality, Performance...
