Summary of Contents for ACME DOT
-
Page 2: Table Of Contents
CONTENTS 01/ Safety Instructions ....................2 02/ Technical Specifications ..................4 03/ Control Panel ......................5 04/ Fixture Installation ....................6 05/ Control By Universal DMX Controller ..............8 5.1 DMX512 Connection ..................8 5.2 Address Setting ....................9 5.3 DMX512 Configuration ................. 9 06/ Error Information .................... -
Page 3: 01/ Safety Instructions
01/ Safety Instructions Please read the instruction carefully which includes important information about the installation, usage and maintenance. WARNING Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction manual. Important: Damages caused by the disregard of this user manual are not subject to warranty. - Page 4 off the mains power immediately. DO NOT operate in a dirty or dusty environment. DO clean the fixture regularly. DO NOT touch any wire during operation as there might be a hazard of electric shock. Avoid entanglement of the power cord with other wires. ...
-
Page 5: 02/ Technical Specifications
02/ Technical Specifications Power Voltage 180-240V~ 50/60Hz Power Consumption Light Source 1x10W laser module Color Temperature 6000K-8000K Beam Angle 87° 0-100% smooth dimming; outstanding strobe effect with variable Dimmer/Strobe speed DMX Channel 5 Channels DMX512 Control Control Mode Primary/Secondary Mode Firmware Upgrade Firmware Upgrade via DMX link Data In/Out... -
Page 6: 03/ Control Panel
03/ Control Panel For DMX512 link, use a network cable to link the unit and the DMX 1. DMX IN controller 2. DMX OUT For DMX512 link, use a network cable to link the next units 3. POWER To connect to supply power - 5 -... -
Page 7: 04/ Fixture Installation
04/ Fixture Installation DO install and operate by qualified operator. Fixture(s) should be installed in areas outside walking paths, seating areas, or away from areas were unauthorized personnel might reach the fixture by hand. NEVER stand directly below the fixture(s) when rigging, removing or servicing. - Page 8 Fix the fixture on the ceiling: 1. Drill an expansion screw hole (for M12 expansion screw) in the ceiling. 2. Unscrew the washer and nut of the expansion screw, and insert the expansion screw tube and screw into the drilled screw hole. 3.
-
Page 9: 05/ Control By Universal Dmx Controller
05/ Control By Universal DMX Controller 5.1 DMX512 Connection 1. To avoid erratic behavior, make sure that the output of the last DMX device in the chain is terminated by a resistor (120-ohm 1/4W) which is connected between RJ45 PIN 1 (XLR PIN 3) and RJ45 PIN 2 (XLR PIN 2) of a RJ45 connector (a male XLR connector). -
Page 10: Address Setting
5.2 Address Setting If you use a universal DMX controller to control the units, you have to set DMX address between 1 and 512 so that the units can receive DMX signal. Please refer to the following diagram to address your DMX512 channel for the first 4 units. Unit 1 Unit 2 Unit 3... - Page 11 SHUTTER 000-007 Stop 008-015 Open 016-255 Shutter from Slow to Fast SHOW MODE 000-045 Null 046-087 Show 1 088-129 Show 2 130-171 Show 3 172-213 Show 4 214-255 Show 0 (Random Show 1-4 Effect) - 10 -...
- Page 12 RDM functions: Certain menus of the device and functions can be called up via the RDM protocol. The parameter IDs are implemented as follows for different commands: Command Command Command Parameter ID ‘Discovery’ ‘Set’ ‘Get’ DISC_UNIQUE_BRANCH √ √ √ DISC_MUTE √...
-
Page 13: 06/ Error Information
RESET_DEVICE √ √ √ CURVE √ √ SHOW_MODE √ √ PRIMARY_SECONDARY √ √ DMX_STATE √ √ DIMMER_SPEED √ √ MOTOR_OFFSET √ √ √-Command implemented for the respective parameter ID 06/ Error Information Led Temp. Error Check whether the temperature detecting board is normal. Check whether the components of the temperature detecting board are damaged. -
Page 14: 07/ Troubleshooting
07/ Troubleshooting Following are a few common problems that may occur during operation. Here are some suggestions for troubleshooting: A. The unit does not work and no light Check the connected power. Measure the voltage. Check the power indicator to see whether it can be lit up or not. B. - Page 15 - 14 -...
