Draper FOUNDATION Installation Manual page 29

Foundation
Section 14 - Attaching LED Panels LED Cabinets
NOTE: All trim brackets and the Bottom Trim Panels MUST be installed
Section 14.1 - Attaching Spring-Loaded Fasteners
1. Replace the mounting bolts
(pre-installed by LED manufacturer)
Spring Loaded mounting studs.
Section 14.2 - Attaching LED Panels
1. Starting in the bottom left corner, insert the four
The head of the studs will engage with the back side of the vertical rail and the spring washer will remain on the front face
Once the head of all 4 studs are fully inserted, lower the panel into the final location.
LED PANEL PLACEMENT
OUTER COLUMNS
(Left & Right Sides)
LED
CABINET
Mounting Holes
NOTE: All 4 mounting studs must be fully
seated at the bottom of the slot.
FRONT
VIEW
for LED Panels
™
in the LED cabinet with the provided
Spring-Loaded Mounting studs into the angled slots on the vertical rail as shown.
(4)
BACK VIEW
before installing LED CABINETS
(Section 13)
M10 Spring-Loaded
LED Mounting Stud
(does not fit through the slot)
Right Side
START SEATED
page 29 of 32
4 per panel
.
