Draper FOUNDATION Installation Manual page 6

Foundation
Section 2 - Trim Frame Components
(continued)
TOP LEFT TRIM SECTION
LEFT
TOP TRIM
SECTION
LEFT
BOTTOM LEFT TRIM SECTION
BOTTOM
TRIM
SECTION
for LED Panels
™
TOP CENTER TRIM SECTION
SOCKET HEAD
SCREW
M4-0.7x10mm
SPLIT LOCK
WASHER
M4
TOP & SIDE
TRIM
ATTACHMENT
BRACKET
BOTTOM TRIM
ATTACHMENT BRACKET
Single - C002.1728
BOTTOM CENTER TRIM SECTION
TOP RIGHT TRIM SECTION
BLACK SOCKET
HEAD SCREW
M4-0.7x10mm
BOTTOM RIGHT TRIM SECTION
page 6 of 32
RIGHT
TOP TRIM
SECTION
RIGHT
BOTTOM
TRIM
SECTION
