  • Page 1 VISUAL COMMUNICATION PRODUCTS I N T E R N A T I O N A L...

  • Page 2: Table Of Contents

    +1 765-987-7999 | www.draperinc.com Building on our experience since 1902 Since 902, DRAPER, INC. has been owned and managed in Spiceland, Indiana by Luther O. Draper’s family with the same business philosophy: make a quality product and offer it at a reasonable price.

  • Page 3: Selection Guidelines & Motorized Screen Controls

    Low Voltage Controls—Available with one or more attractive 3-button switches ➌. Control unit, without switches, is compatible with master control systems. It is equipped with jacks for connection with Draper RF or IR receivers. Wiring from control unit to switches is lightweight for 24-volt current.

  • Page 4: Quiet Motors & Controls

    DRAPER motorized projection screens are standardly provided with a 0VAC or 220VAC motor. Our standard motor is compatible with the motorized screen controls shown on page 3. Many DRAPER motorized projection screens will soon be available with quiet motors or built-in low voltage controllers.

  • Page 5: Screen Surfaces And Gain Charts

    M2500 100% vinyl stretchable matt white surface, with excellent clarity and uniform Gain 3.0 brightness over an extremely broad viewing angle. It is washable. This is part of the Draper EcoVision range of products. M2500— More than twice as bright as ordinary Matt White, with a full 180° viewing cone, excellent contrast and resolution.

  • Page 6: Motorized Projection Screens

    Motorized Projection Screens +1 765-987-7999 | www.draperinc.com ARONET Small Electric Screen The BARONET is a compact electric screen with the motor inside the roller. It is our most economical, and most popular motorized screen. Universal mounting brackets make installation easy whether the BARONET is mounted on a wall, suspended or recessed above the ceiling.

  • Page 7: Targa & Premier

    Motorized Projection Screens +1 765-987-7999 | www.draperinc.com REMIER With Flat Surface ������ Designed specifically for video and data projection. A sophisticated Tab ���� Tensioning System holds the viewing surface flat and wrinkle free. Featuring a quiet motor-in-roller design, the Premier is available with M1300, M2500 or HiDef Grey front screen viewing surfaces.

  • Page 8: Salara

    RS232. Motor is hardwired like all standard DRAPER motorized screens. Plug & Play™ Version—With DRAPER’S Plug & Play option, you can have a remote controlled screen on your wall in 0 minutes—...

  • Page 9: Access & Ultimate Access

    The ACCESS or ULTIMATE ACCESS screen itself installs in minutes, and the only tool you need is a hex key. Access/Series V—Motorized screen featuring DRAPER’S Tab Tensioning System, with choice of M300, M2500, HIDEF GREY OR CINEFLEX rear projection viewing surface.
  • Page 10 . No other ❸ projection screen offers you so many benefits. Ultimate Access/Series V Ultimate Access/Series V—Includes DRAPER’S Tab Tensioning System, with choice of 20.3cm M300, M2500, HIDEF GREY or CINEFLEX rear projection viewing surface.

  • Page 11: Signature & Silhouette

    SIGNATURE’S ceiling closure is ������ independently motorized. It disappears into the white case when the screen is lowered. Signature/Series V—Includes DRAPER’S Tab Tensioning System, with choice of M300, M2500, HIDEF GREY or CINEFLEx rear projection viewing surface. Signature/Series V Signature/Series E—Viewing surface of MATT WHITE, GLASS BEADED, HIGH...

  • Page 12: Paragon & Rolleramic

    Motorized Projection Screens +1 765-987-7999 | www.draperinc.com ARAGON Largest motorized projection screen. Sizes through 853 cm (28´) wide or 1067 cm (35´) diagonal. Ideal for auditoriums, lecture halls and any setting where a very large screen is 30.5cm required. White extruded aluminum case can be suspended anywhere.

  • Page 13: Manual Projection Screens

    CREENS workmanship for five (5) years from date of shipment from manufacturer. The DRAPER V SCREEN is the longest lasting classroom wall screen, at a very reasonable price. Its design is extremely simple. The screen roller is supported by a strong aluminum bar. The V SCREEN has durable components and a tearproof MATT WHITE viewing surface.

  • Page 14: Luma & Luma 2

    Manual Projection Screens +1 765-987-7999 | www.draperinc.com Finest wall/ceiling screen The LUMA is DRAPER’S finest spring-roller 12cm operated projection screen. Its pentagonal steel case and endcaps are finished in white. The case is designed to be attractive, sturdy and friction-free. The LUMA is available with MATT WHITE, GLASS BEADED or HIGH CONTRAST GREY viewing surface.

  • Page 15: Roadwarrior, Traveller, & Piper

    ARRIOR Ultra-portable screen for today’s projectors The DRAPER ROADWARRIOR lets you travel light and sets up in seconds—on the floor or table. Release two clasps to open the lid. Rotate feet into position for stability. Screen height adjusts instantly. At the touch of a finger, extend the screen to desired height (pneumatic cylinders support it at any level).

  • Page 16: Diplomat & Consul

    Elegant Workmanship and High Quality The DIPLOMAT offers simplicity of design, heavy gauge components and careful workmanship. DRAPER’S patented Bell Leg Lock prevents the tripod legs from being bent or broken. Steel case and endcaps are finished in black. A one-piece, die cast handle is designed to permit adjustment of case height with one hand.

  • Page 17: Ultimate Folding Screen

    Combine these advantages with clear anodized 3 cm (.25) x .070 wall aluminum tubing and you’ve got the precision and stability that allows DRAPER to offer the ULTIMATE FOLDING SCREEN in sizes through 386 cm x 508 cm (52 X 200).

  • Page 18: Cinefold & Truss Cinefold

    CINEFLEX for rear projection. Bordered in black, surfaces are interchangeable. • Carrying Case—The CINEFOLD comes packed in DRAPER’S heavy-duty, molded polyethylene carrying case. Each case has two wheels. The handles are molded into each end of the case. Lid handle is steel with a rubber grip and recessed in an inset.
  • Page 19 Portable Projection Screens +1 765-987-7999 | www.draperinc.com RESS For a professional appearance Create a professional, theatre-like appearance by draping your ULTIMATE FOLDING SCREEN, CINEFOLD or TRUSS CINEFOLD with a velour DRESS KIT. All DRESS KIT fabrics are flame proofed. With rear-projection screens, the velour curtains will hide projection equipment, shield projector light from the audience, and help eliminate ambient light in the projection area.

  • Page 20: Rear Projection Screens And Systems

    +1 765-987-7999 | www.draperinc.com NNOVATIVE OLUTIONS Established in 902, DRAPER is one of the world’s largest and foremost manufacturers of front and rear projection screens. Since 985, DRAPER has developed a particular expertise in the design and manufacture of custom videowalls, projector support structures and related products for electronic information display.

  • Page 21: Cineplex & Irus

    • Unique anti-glare finish on a 0.6 cm (¼) acrylic substrate • .0 gain across a 80° viewing cone The DRAPER IRUS IS specifically designed to provide maximum legibility with any projector. Today’s SXGA and UXGA displays offer higher • Sizes through 305 cm (20) diagonal resolutions than ever before—and that means more information for your...

  • Page 22: Diamondscreen & Vortex

    Vortex not available in these sizes. These DiamondScreens require a Large Screen System DRAPER furnishes first surface glass mirrors for use in custom rear frame. The frame ships disassembled. When projection rooms. The mirrors are optical grade glass, 94% reflective, and 6 assembled, it adds 4.13 cm (⅝) to the overall...

  • Page 23: Rpx And Videowalls

    Screens are assembled with “zero” visible separation. Actual screen separation is approximately 0.5 mm. Modules VideoWalls may be installed in-wall or can be incorporated in a freestanding DRAPER Full information available at: MULTISCREEN SYSTEM. With Zero Edge, screen sizes cannot exceed 305 cm www.draperinc.com/go/VideoWalls.htm...

  • Page 24: Orbiter And Phantom Lifts

    • The projector is easily aligned and fine-tuned during installation to provide a direct light path onto your DRAPER projection screen. • Supplied with a universal bracket that allows for easy attachment of a variety of projector models.

  • Page 25: Projector Lifts

    Optional for all DRAPER video projector lifts. Wiring from control unit to switches is for 24V current. • Wireless Remote Control—Enables you to operate a DRAPER video projector lift from anywhere in the room. For use only with DRAPER low-voltage control unit, with or without wall switches.

  • Page 26: Revelation & Scissor Lift

    You won’t see or hear the projector. While other projector lifts lower the projector into the room from a ceiling recess, or lift it into the seating area from a table hideaway, the DRAPER REVELATION hides the projector—and its noise—above the ceiling, all the time.

  • Page 27: Lcd Lift & Aerolift

    The AEROLIFT 50 and 50 hold 22.7 kg and 68 kg respectively (50 and 50 lbs.), and have a larger overall size. Contact DRAPER for more details. All are powered by strong tubular motors for a simplified design, and features a stabilizing arm which can be used for cable management.

  • Page 28: Permanently Tensioned Projection Screens

    The 0 cm (4) wide beveled, extruded aluminum frame assembles on site with one simple hand tool that DRAPER provides. Each side piece slip-fits tightly to injection molded plastic corners, forming perfectly mitered edges. A new approach to fabric attachment will amaze even the toughest of critics.
