ST STM32U5 User Manual page 35

MCU STM32
function
TIM1_CH1 PA8
TIM4_ETR PE0
1. The default configuration for the D0/D1 signal is LPUART1 on PG7 and PG8, USART1 on PA9 and PA10 is connected by
default on STLINK-V3E.
2. PG2 to PG15 can have a different I/O level to other I/Os because supplied by VDDIO.
3. I/O shared between ADC and QSPI (exclusive)
4. I/O shared between QSPI and motor control (exclusive)
5. I/O shared between SAI_D, SPI_B, and UCPD function (exclusive)
6. I/Os are shared between SAI and JTAG SWO (exclusive)
7. SAI_D and SAI_B groups are on the same SAI instance (exclusive).
8. SAI_D group is shared with SPI_B group, (exclusive).
UM2861 - Rev 2
Signal name Pin name
pin
TIM_D_PWM1 D33
TIM_B_ETR D34
Zio connectors supporting ARDUINO® Uno V3
Pin Pin Pin name Signal name
31 32 (4) TIM_C_PWM2
D36
33 34 D35 TIM_C_PWM3
UM2861
STM32 MCU
pin function
PB10 TIM2_CH3
PB11 TIM2_CH4
page 35/49
