function name
CCSSPVC 87
FUFSPVC
VDSPVC 60
DELVSPVC 7V_78V
DELISPVC 71
DELSPVC 78
Logic
SMPPTRC 94
SMAGAPC
STARTCOMB
TMAGAPC
ALMCALH
WRNCALH
INDCALH
AND, GATE, INV,
LLD, OR,
PULSETIMER,
RSMEMORY,
SRMEMORY,
TIMERSET, XOR
AND, GATE, INV,
LLD, OR,
PULSETIMER,
RSMEMORY,
SLGAPC,
SRMEMORY,
TIMERSET,
VSGAPC, XOR
FXDSIGN
B16I
BTIGAPC
IB16
ITBGAPC
TEIGAPC
INTCOMP
REALCOMP
HOLDMINMAX
INT_REAL
CONST_INT
INTSEL
Table continues on next page
Transformer protection RET670
Commissioning manual
Function description
Current circuit supervision
Fuse failure supervision
Fuse failure supervision based on voltage difference
Voltage delta supervision, 2 phase
Current delta supervision, 2 phase
Real delta supervision, real
Tripping logic
General start matrix block
Start combinator
Trip matrix logic
Logic for group alarm
Logic for group warning
Logic for group indication
Basic configurable logic blocks (see Table 3)
Extension logic package (see Table 7)
Fixed signal function block
Boolean to integer conversion, 16 bit
Boolean to integer conversion with logical node representation, 16 bit
Integer to Boolean 16 conversion
Integer to Boolean 16 conversion with Logic Node representation
Elapsed time integrator with limit transgression and overflow supervision
Comparator for integer inputs
Comparator for real inputs
Hold minimum and maximum of input
Converter integer to real
Definable constant for logic functions
Analog input selector for integer values
