Control Surface Deflections and Expo Settings

NOTE: The BVM Demo plane is set up using the following Expo percentages. Positive
values are used on Spektrum and JR radios, Futaba uses negative.
Control
Stab (measured at the fuse side.)
Aileron (measured at the tip)
Flaps (measured at the Aileron)
Rudder (measured at the Bot.)

DX20,DX18, and DX18QQ Transmitter File

The BVM Demo models are setup on Spektrum DX20 transmitters. The file included on the
SD card has all the mixes, rates, expos, and settings done for you. Setting the sub trim,
switches, and travel adjustment must be accomplished by the modeler for the specific
aircraft.
Important!!! Check the directions of all flight controls before each flight.
Switch/Lever/Trimmer Channel
Switch A
Switch D (Flight Modes)
Switch E
L. Trim
Switch F
Switch G
Switch C
BVM ® 2020
F-86 Sabre
Assembly & Operation Manual
High Rate Travels
Up 1.25"
UP .70"
Take Off 1.6"
L&R 1.5"
(12) Aux 7 Gear
Flaps
Brakes (8) Aux 3
Steering Trim (13) X+1
Aileron/ Elevator, Rudder Rates
Gyro (10)
Speed Brakes (11) Aux 6
15
Expo D/R M
Down 1.0" 20 80%/15
Down .70" 20 80%/15
Landing 3"
20 80%/15
Output
Landing Gear, Down is Down
Up is Normal flight
Mid Take Off
Down is Landing
Pos 0-off, Pos 1-pulse, Pos 2-stop
Up for Right Steering Trim
Down for Left Steering Trim
Up (0) is High
Pos 0- off, Pos 1- low, Pos 2- high
D/R L
60%/10
60%/10
60%/10
