3-2. Use Philips screwdriver to release terminal screws.
3-3. Fold the wire end to pass through the conduit and insert them into the input hole.
3-4. Fix the copper wire on the corresponding terminal block. The wiring instruction is printed
in front of the terminal block (L1/L2/G).
3-5. Use the following torque to connect the wire terminal to the terminal block.
3-6. The recommended terminal specifications are as following.
Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0
12
BlinkCharging.com • (888) 998.2546
©2021 Blink Charging Co. • NASDAQ: BLNK
Screw
M4 16 kgf.cm
Terminal Dimension(mm)
W
d2
Figure 2-12 Input wiring
Torque
13.88 lb-in
≤ 9.5
4-6.4
