2. Mount charge point onto mounting bracket and lock the screw.
2-1. Put the charge point on the mounting bracket.
2-2. Fix the charge point on mounting bracket by M4 screw and screw washer.
2-3. Please refer to the following torque.
9
Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0
BlinkCharging.com • (888) 998.2546
©2021 Blink Charging Co. • NASDAQ: BLNK
Screw
M4
16 kgf.cm
Figure 2-6 Charge point and mounting bracket
Figure 2-7 Tighten M4 screw
Torque
13.88 lb/in
