2. Find SIM card socket
3. Insert SIM card
3-1. Push down the cover to open SIM card socket.
3-2. Prepare the SIM card. (Use micro-SIM, 15mm x 12mm.)
3-3. Insert the SIM card.
3-4. Close the SIM card socket and push the cover toward lock direction to lock the cover.
3-5. Reassemble the top cover. Please refer to the following torque. SIM card installation is
completed.
6
Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0
BlinkCharging.com • (888) 998.2546
©2021 Blink Charging Co. • NASDAQ: BLNK
Figure 2-2 Position of SIM card socket
Figure 2-3 SIM card socket and cover Open/Lock direction
Screw
M4
Torque
16 kgf.cm
13.88 lb-in
