Installation Manual
Basic/Smart/Intelligent Charger-32A Revision 4.0
BlinkCharging.com • (888) 998.2546
©2021 Blink Charging Co. • NASDAQ: BLNK

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Basic Charger-32A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Blink Basic Charger-32A

Summary of Contents for Blink Basic Charger-32A

  • Page 1 Installation Manual Basic/Smart/Intelligent Charger-32A Revision 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...
  • Page 2 Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...
  • Page 3 This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with greater than 20cm between the radiator & your body. Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...
  • Page 4 Do not modify the plug provided with the product – if it will not fit the outlet, have a proper outlet installed by a qualified electrician. Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...
  • Page 5 CAUTION: Do not use this product if there is any damage to the unit. Send the unit back to the manufacturer in the event the unit is not operational. SAVE THESE INSTRUCTIONS Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...

  • Page 6: Table Of Contents

    SIM Card Installation (for IC3 only) ................5 Install the Charge Point ....................7 Input cord connection (for IC3 only) ................11 Install the Holster....................... 15 Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...

  • Page 7: Introduction

    !!! Any unauthorized modifications will void the manufacturer’s warranty. !!! 1.1 Product View Different models of Charger: Basic Charger-32A (BC3) Smart Charger-32A (SC3) Intelligent Charger-32A (IC3) Figure 1-1 Front view Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...
  • Page 8 Attached to the back of the charge point With Hook x1, Holster x1 & M4xL15 tapping Holster ASSY screw x2 Screw Bag With #12xL50 tapping screw x4 Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...

  • Page 9: Installation

    Use a wire with a dedicated grounding wire and a ring terminal and connected to the equipment ground terminal block for grounding. Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...

  • Page 10: Tools & Parts Required For Installation

    2.3 SIM Card Installation (for IC3 only) 1. Disassemble top cover 1-1 Loosen the screws (x5) on the base cover. Figure 2-1 Position of five screws on Base Cover Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...
  • Page 11 3-4. Close the SIM card socket and push the cover toward lock direction to lock the cover. 3-5. Reassemble the top cover. Please refer to the following torque. SIM card installation is completed. Screw Torque 16 kgf.cm 13.88 lb-in Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...

  • Page 12: Install The Charge Point

    Figure 2-4 Secure mounting bracket Figure 2-5 Screw holes of mounting bracket Screw suggestion: For masonry walls, use M6 mechanical screws. (Commercially Available) Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...
  • Page 13 Please refer to the following torque. The actual torque is according to the wall material. Screw Torque 25 kgf.cm min 21.7 lb-in min 25 kgf.cm min 21.7 lb-in min Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...
  • Page 14 2-3. Please refer to the following torque. Screw Torque 16 kgf.cm 13.88 lb/in Figure 2-6 Charge point and mounting bracket Figure 2-7 Tighten M4 screw Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...
  • Page 15 The outlet should be located at 20-26 inch from the ground. Refer to the installation template to decide where to install the charge point. Figure 2-8 Plug in the power cord Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...

  • Page 16: Input Cord Connection (For Ic3 Only)

    90C copper wire Figure 2-11 Copper terminal, heat shrink tube and copper wire. 3. Electrical wiring to the charge point. 3-1. Disassemble top cover. Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...
  • Page 17 Screw Torque 16 kgf.cm 13.88 lb-in 3-6. The recommended terminal specifications are as following. Terminal Dimension(mm) ≤ 9.5 4-6.4 Figure 2-12 Input wiring Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...
  • Page 18 The outlet must be installed properly to maintain the proper NEMA rating of the enclosure. Model Current Rating Intelligent Charger-32A 32 A Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...
  • Page 19 Torque 1 “ 35 kgf.cm 30.36 lb-in 3-8. Reassemble top cover. Please refer to the following torque. Screw Torque 16 kgf.cm 13.88 lb-in Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...

  • Page 20: Install The Holster

    2-1. For finished walls supported by wood studs, use #12 tapping screws (x2). 2-2. The recommend torque is 25 kgf.cm (21.7 lb-in). Figure 2-15 Secure the hook Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...
  • Page 21 3. Make the holster face up and combine with the hook. Figure 2-16 Secure the holster 4. Rotate the holster down totally. Figure 2-16 Rotate the holster Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...
  • Page 22 5. Keep the holster in this state and tighten screws completely. Figure 2-17 Lock screws 6. Place EV charging plug on the holster. Figure 2-18 Place EV charging plug Basic/Smart/Intelligent Charger-32A Installation Manual Rev. 4.0 BlinkCharging.com • (888) 998.2546 ©2021 Blink Charging Co. • NASDAQ: BLNK...

This manual is also suitable for:

Smart charger-32aIntelligent charger-32a
