Product Specifications - SHOWTEC Compact Par 7 Q4 User Manual

Compact Par 7 Q4

Product Specifications

Model:
Electrical:
Input voltage:
Power consumption:
Fuse:
Physical:
Dimensions:
Weight:
Optics:
Light source:
Luminous flux:
Illuminance @ 2 m:
Dimmer:
Strobe:
Beam angle:
Drive current:
Refresh rate:
Operation and control:
Control:
DMX channels:
Control panel:
Connections:
Power connections:
Data connections:
Signal pinouts:
Construction:
Housing:
Color:
IP rating:
Cooling:
Thermal:
Maximum ambient temperature t
Minimum operating temperature:
Minimum distance:
Minimum distance from flammable surfaces:
Minimum distance to lighted object:
Product code: 42584
Compact Par 7 Q4
100–240 V AC, 50/60 Hz
32 W
T 1,5 A, 250 V
275 x 258 x 92 mm (L x W x H)
2,16 kg
7 x 4 W 4-in-1 RGBW LEDs
1100 lm
2201 lx
0–100 %
0–20 Hz
15°
330 mA
7800 Hz
Stand-alone (auto, manual, sound-controlled)
Master/Slave (auto, manual, sound-controlled)
DMX-512
4, 6, 11 channels
4-digit LED display and buttons
IEC (C14) power connector IN
3-pin DMX connectors IN/OUT
Pin 1 (ground), pin 2 (-), pin 3 (+)
Extruded aluminum and metal plate
Black
IP20
Aluminum heatsink
: 40 °C
a
-10 °C
0,5 m
0,5 m
10
