Compact Par 7 Q4
3.
Description of the Device
The Showtec Compact Par 7 Q4 is a compact par, equipped with 7 x 4 W RGBW LEDs. It is suitable for
indoor venues and has a double bracket for easy floor positioning. It has a fixed 15° beam angle and is
perfect for short-throw color mixing.
Front View
Back View
Top View
Product code: 42584
01) 7 x 4 W RGBW LEDs
02) 2 x Adjustment screws
03) Mounting bracket
Fig. 02
04) Air vents
05) Control panel: 4-digit LED display and buttons
06) Ground contact
Fig. 03
07) 3-pin DMX signal connector OUT
08) 3-pin DMX signal connector IN
09) IEC (C14) power connector IN
10) Fuse T 1,5 A, 250 V
Fig. 04
9
