Compact Par 7 Q4
4 CH 6 CH 11 CH
6
7
1 3 8
2 4 9
3 5 10
4 6 11
Note:
● Make sure that the Master Dimmer channel is open in 6-CH and 11-CH mode in order to see the light
output.
● If you play the built-in chases in 11-CH mode, the strobe (CH 2 and CH 3) and the master dimmer
(CH 1) channels are not functional.
● The Speed channel in 11-CH mode works only in combination with the built-in chases in CH 5.
Product code: 42584
Function Value
192–207
208–223
224–239
240–255
000–255
Speed
000–050
Sound Mode
051–255
Red 000–255
Green 000–255
Blue 000–255
White 000–255
Setting
Fade 4
Fade 5
Fade 6
Fade 7
Speed adjustment of the built-in chases, from slow
to fast
No function
Sensitivity adjustment, from low to high (0–100 %)
From low to high intensity (0–100 %)
From low to high intensity (0–100 %)
From low to high intensity (0–100 %)
From low to high intensity (0–100 %)
25
