Compact Blinder 2

Description of the device

Features
The Compact Blinder 2 is a blinder system from Showtec.
 Input voltage: 240V AC, 50Hz
 Power consumption: 430W
 Light source: 2 x GY5.3 120V/250W (not included)
 Housing: Metal & flame retardant plastic
 Color: Black
 Connections: Schuko power cable (1,5 m)
 IP rating: IP20
 Fuse: F5L/250V
 Dimensions: 420 x 70 x 350 mm (LxWxH)
 Weight: 2,7 kg
Optional accessories:
70359 – 50 mm Quick Coupler
80808O – Osram Projection Bulb ENH GY5.3

Frontside

Fig. 01
01) Barn door
02) GY5.3 lamp housing
03) Schuko power cable (1,5 m)
04) Mounting bracket with inclination screw
05) Adjustment screw
Ordercode: 30605
