Daikin MICROTECH III Operating Manual page 64

Solid Green
Solid Yellow
Solid Red
Flashing Yellow
Bacnet MSTP:
BuS LED
Solid Green
Solid Yellow
Solid Red
Bacnet IP:
BuS LED
Solid Green
Solid Yellow
Solid Red
Modbus
BuS LED
Solid Green
Solid Yellow
Solid Red
D–EOMWC00A07-16_02EN
Ready for Communication. (All Parameter loaded, Neuron configured). Doesn't
indicate a communication with other devices.
Startup
No Communication to Neuron (internal error, could be solved by downloading a new
LON application).
Communication not possible to the Neuron. The Neuron must be configured and set
online over the LON Tool.
Mode
Ready for Communication. The BACnet Server is started. It doesn't indicate a active
communication.
Startup
BACnet Server down. Automatically a restart after 3 seconds are initiated.
Mode
Ready for Communication. The BACnet Server is started. It doesn't indicate a active
communication.
Startup. The LED stays yellow until the module receives a IP Address, therefore a link
must be established.
BACnet Server down. Automatic restart after 3 seconds is initiated.
Mode
All Communication running.
Startup, or one configured channel not communicating to the Master.
All configured Communications down. Means no communication to the Master. The
timeout can be configured. In case that the timeout is zero the timeout is disabled.
Operation Manual 64/77
