Hand Crimp Tool for
SPOX™
FEATURES
A full cycle ratcheting hand tool ensures complete crimps
Ergonomic soft grip handles for comfortable crimping
A precision user-friendly terminal locator wire stop holds terminals in the proper crimping position
This tool is WHMA-IPCA620 Class 2 and RoHS compliant
SCOPE
Products: Pico-SPOX™ Crimp Female Terminal, 24-30 AWG.
Terminal Order No.
Terminal
Series No.
Loose Piece
87421
DEFINITION OF TERMS
BRUSH
STRIP
LENGTH
The above terminal drawing is a generic terminal representation. It is not an image of a terminal listed in the
scope.
Doc No: ATS- 638116400
Revision: B
Terminals
HAND CRIMP TOOL
SPECIFICATION SHEET
Order No. 63811-6400
Wire Size
Reel
AWG
mm²
24
0.20
87421-0000
26-30
0.12-0.05
Customer to cut off terminal from reel: 0.29mm (.011") maximum Cut-off Tab.
See Conditions on page 2.
BELL MOUTH
INSULATION
CRIMP
Release Date: 06-19-06
Revision Date: 03-29-08
Insulation Diameter
Wire Type
Maximum
AWG
Type
mm
24
UL1061
1.15
26
UL1061
1.00
28
UL1061
30
UL1571
CONDUCTOR
CRIMP
CRIMP HEIGHT
UNCONTROLLED COPY
TYPE 2C
Strip Length
In.
mm
.045
1.05-1.54
.041-.061
.039
1.05-1.54
.041-.061
BEND UP
ROLLING
TWISTING
BEND
DOWN
Page 1 of 6
