4.
Lift off the upper section of the sta-
tion to expose the fan plate in the
lower section.
Installing the Sensor Interface Module (SIM) Battery:
1.
Locate the SIM
inside the
upper section
of the station.
Page 4
Aspirated
Radiation
Shield
Lower
Section
Locating the Sensor Interface Module
Upper
Section
Separating the Radiation Shield
Sensor Interface
Module (SIM)
Solar Panel Cable (+V SOL)
SIM Power Cable (+V SIM)
Sensor Interface Cable
Wireless Temperature/Humidity Station
Fan Plate
