Place the shelter at the intended mounting site, or have someone hold it there,
so you can walk around with the console/receiver for a few minutes. Rotating
the antenna may help to improve reception.
Test wireless reception anywhere you might want to use or mount your con-
sole/receiver now or in the future. Take your time. If you aren't picking up
strong signals where you intend to place your console, better to move the sta-
tion now than after it has been mounted. Experiment.
M
OUNTING THE
It can be mounted on a pole or on a vertical surface such as a wooden post.
Mounting on a Pole
Use a pole having an outside diameter between 1" and 1-1/4" (25 – 31 mm).
1. Slide the stud ends protruding from the top of the station through the holes on the
mounting bracket.
2. Secure the station to the mounting bracket using a #8 flat washer, #8 split lock
washer and #8 hex nut one each of the stud ends.
Tighten the hex nuts until the station is secure on the mounting bracket.
A
TTACHING
Page 8
T
EMPERATURE
#8 Hex Nut
#8 Lock Washer
#8 Flat Washer
Temperature/
Humidity Station
T /H
EMPERATURE
/H S
UMIDITY TATION
Threaded Stud Ends
S M
UMIDITY TATION TO OUNTING
B
RACKET
