Installing the Device
2.6 Connecting Power
2.6
Connecting Power
The RUGGEDCOM RS401 supports a single integrated high AC/DC or low DC power
supply
Note
•
•
•
•
•
•
2.6.1
Connecting AC Power
To connect a high AC power supply to the device, do the following:
NOTICE
Electrical hazard – risk of damage to equipment
Before testing the dielectric strength (HIPOT) in the field, remove the braided
ground cable connected to the surge ground terminal and chassis ground. This cable
connects transient suppression circuitry to chassis ground and must be removed in
order to avoid damage to transient suppression circuitry during testing.
16
For 88-300 VDC rated equipment, an appropriately rated circuit breaker must be
installed.
For 100-240 VAC rated equipment, an appropriately rated circuit breaker must
be installed.
Use only #16 gage copper wiring when connecting terminal blocks.
A circuit breaker is not required for 12, 24 or 48 VDC rated equipment.
Power input terminals have reverse polarity protection for 12, 24 and 48 VDC rat-
ed equipment.
Equipment must be installed according to applicable local wiring codes and stan-
dards.
RUGGEDCOM RS401
Installation Manual, 01/2020, C79000-G8976-1017-09
