To mount the device to a panel, do the following:
1.
RUGGEDCOM RS401
Installation Manual, 01/2020, C79000-G8976-1017-09
Place the device against the panel and align the adapters with the mounting
holes.
1 1
1
Screw
1
Panel/DIN Rail Adaptor
2
Figure 2.5
Panel Mounting (Front Mount Orientation)
Installing the Device
2.3.2 Mounting the Device to a Panel
2
13
