1.3 Required Tools and Materials
Ethernet Port Status LEDs
Communication Ports
RS-232 Console Port
Failsafe Alarm Relay
Power Supply Terminal Block
1.3

Required Tools and Materials

The following tools and materials are required to install the RUGGEDCOM RS401:
AC or DC power cord (16 AWG)
Multi-mode and/or single-mode fiber optic cables
CAT-5 Ethernet cables
Flathead screwdriver
Phillips screwdriver
4 x #6-32 screws
1.4

Decommissioning and Disposal

Proper decommissioning and disposal of this device is important to prevent malicious
users from obtaining proprietary information and to protect the environment.
