AMP Research PowerStep 77122-01A Installation Manual page 3

A M P R E S E A R C H P O W E R S T E P
A
1
x2
Running board assembly
2
x2
Rail Assembly
3
Motor Linkage assembly
Driver
www.amp-research.com
F
(A) End cap left (x1)
(B) End cap right (x1)
(C) T-nut insert (x2)
(D) Socket cap screw (x2)
(E) End cap wedge right (x1)
(F) End cap wedge left (x1)
4
Motor Linkage assembly
Passenger
– J e e p W r a n g l e r J K
T M
3/11
C
E
D
B
5
x2
Idler Linkage assembly
IM77122 rev 01.21.20
