APPLICATION
Chevrolet Silverado 1500/GMC Sierra 1500 - Crew Cab
Note: The application works only on the Crew Cab model Vehicles.
AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 6:00 AM - 5:00 PM PST
Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the following patents:
6,641,158; 6,830,257; 6,834,875; 6,938,909; 7,055,839; 7,380,807; 7,398,985; 7,584,975 ©2012 AMP Research. All rights reserved.
Printed in USA.
www.amp-research.com
I N S T A L L A T I O N G U I D E
1/11
AMP Part#
2019
77254-01A
INSTALLATION TIME
3-5 Hours
Professional installation recommended
SKILL LEVEL
1 2 3
4= Experienced
TOOLS REQUIRED
q Safety goggles
q Measuring tape
q Power Drill
q 10 mm socket
q 13 mm socket
q 1/2" socket
q Ratchet wrench and extension
q Wire crimpers
q Wire stripper / cutter
q
3 /16" hex key wrench (allen wrench)
q
4mm hex key wrench ( allen wrench )
q
Electrical tape
q
Weather proof caulking (silicone sealer)
q
Silicone spray
WARRANTY
5-Year Limited Warranty
4
IM77254 rev 02.18.19
Advertisement
Related Manuals for AMP Research PowerStep 77254-01A
Summary of Contents for AMP Research PowerStep 77254-01A
- Page 1 AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 6:00 AM - 5:00 PM PST Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the following patents: 6,641,158; 6,830,257; 6,834,875; 6,938,909; 7,055,839; 7,380,807; 7,398,985; 7,584,975 ©2012 AMP Research. All rights reserved.
-
Page 2: Exploded View
A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C INSTALLATION GUIDE Attaching motor to Linkage assembly. EXPLODED VIEW Motor Socket cap screw... - Page 3 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C (A) End cap left (x1) (B) End cap right (x1) (C) T-nut insert (x2) (D) Socket cap screw (x2) (E) End cap wedge right (x1)
- Page 4 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Controller STA Posi-Lock™ M8 Hex Bolt w Wire harness Conical washer Socket Cap...
- Page 5 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Nut Plates Button Head Bolt LED Lamp LED Light Bracket Gear Cover Motor...
- Page 6 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Remove plastic body plugs in three locations shown. Using supplied M8 Conical washer bolts(9), Install brackets(25,26,27) onto truck as shown.
- Page 7 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Slide mounting T-nut into position, Center board in Using a 13mm socket Torque linkage bolts 4x (9) rail pocket.
- Page 8 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Attach motor to linkage. Using a 4mm hex Torque Remove the fuse from the Powerstep wire harness.
- Page 9 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Remove the driver side door sill trim and and kick Route wire harness along the frame and back towards rear linkages.
- Page 10 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C OBD II install: Use Supplied Posi Twist connectors to attach the Plug and Play Module to the Harness.
-
Page 11: Final System Check
A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Check that all doors activate the Power Step and the LED Lights work when doors open and close. -
Page 13: Year Limited Warranty
5-YEAR LIMITED WARRANTY AMP RESEARCH warrants this product to be free from defects in material and workmanship for FIVE (5) YEARS FROM DATE OF PURCHASE, provided there has been normal use and proper maintenance. This warranty applies to the original purchaser only.
